Canon imagePRESS Lite C170 Series Service Guide
imagePRESS Lite C170 Series Service Guide March 2022
Revision 11 Page 78
Table 43 – Multi Function Professional Puncher- Maintenance Items
Multi Function Professional Puncher Periodic Maintenance
Part Name
Estimated
Interval
68
Action Remarks
Punch drive cams
1,000,000
sheets
Inspect &
Lubricate
Lubricated with grease
Punch motor belt
1,000,000
sheets
Inspect
Alignment stepper belt
1,000,000
sheets
Inspect
Steering carriage belt
1,000,000
sheets
Inspect
Steering rollers
1,000,000
sheets
Inspect &
Clean
Punch clutch
1,000,000
sheets
Clean
High speed sensors
500,000
sheets
Clean
Air blow
Drive and Idler rollers
1,000,000
sheets
Inspect &
Clean
Alcohol & cloth
Solenoid module
1,000,000
times
Inspect
Paper path sensors
500,000
sheets
Clean
Air blow
Idler panel closing magnet
latches
1,000,000
sheets
Inspect
Acceleration panel latch
1,000,000
sheets
Inspect
Paper path drive timing belts
1,000,000
sheets
Inspect & □
Diverter solenoid assembly
1,000,000
sheets
Inspect
Die set recognition board clips
1,000,000
sheets
Clean
Standard Punch Die (Pin)
250,000
times
Inspect &
Lubricate
Maintenance by users Lubricated
with oil
High durability punch die (pin)
250,000
times
Inspect &
Lubricate
Maintenance by users
Lubricated with oil
High durability punch die
(shoulder bolt)
750,000
times
Inspect &
Lubricate
Maintenance by users Lubricated
with grease
68 Value is based on LTR sized paper. Estimated average values in the field, based on data from
supplier. Data is subject to change depending upon many factors including, without limitation,
monthly copy volume, environment, type of image printed and customer handling of the equipment.
