Canon imageprograf IPF785 User Manual

Specifying Paper in the Printer Driver
Specifying Paper in the Printer Driver
If you have replaced the paper, you must complete the following settings in the printer driver.
Important
• Always specify the same type and size of paper in the printer menu and printer driver.
1 Choose Print in the application menu.
2 Select the printer in the dialog box, and then display the printer driver dialog box. (See "Accessing the Print-
er Driver Dialog Box from Applications .") ➔ P.148
3
Make sure the Main sheet is displayed.
4 In the AMedia Type list, select the type of paper that is loaded.
Note
• Click the B Get Information button to display the Paper Information on Printer dialog box. On the Pa-
per Information on Printer dialog box, you can obtain information on the paper in the printer and config-
ure printer driver settings for the feed source and type of paper.
This function requires that the Status Monitor be installed.
5
Click the Page Setup tab to display the Page Setup
sheet.
6 In the APage Size list, select the size of the original as specified in the application.
7 In the LPaper Source list, select how paper is supplied.
8 If you have selected roll paper in LPaper Source, select the width of the loaded roll in M Roll Paper
Width.
Specifying Paper in the Printer Driver iPF785
User's Guide
Windows Software Printer Driver
144

Canon imageprograf IPF785 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Storage media	HDD
Internal memory	256 MB
Internal storage capacity	320 GB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
