Canon imageprograf IPF785 User Manual

4 Press ▲ or ▼ to select Output Method, and then press the OK button.
Note
• If a password has been set on the printer, the Logon screen is displayed.
To change the settings, select Administrator and press the OK button. When the Admin.Pswd screen is
displayed, enter the password and press the OK button to proceed to the next step.
If you select User and press the OK button, you can check settings values but cannot change them.
5 Press ▲ or ▼ to select Print, Print (Auto Del), or Save: Box 01.
Follow these steps only when you select Save: Box 01.
6 Press ▲ or ▼ to select the box, and then press the OK button.
Specify Print After Recv
To save print jobs on the hard disk before printing, specify Print After Recv.
Printing will start when Print After Recv is set to On, even if you have selected Save: Box 01 in Output Method.
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to
select the Settings/Adj. tab ( ).
Note
• If the Tab Selection screen is not displayed, press the Menu button.
2 Press the OK button.
The Set./Adj. Menu is displayed.
3 Press ▲ or ▼ to select System Setup, and then press the OK button.
4 Press ▲ or ▼ to select Print After Recv, and then press the OK button.
5 Press ▲ or ▼ to select On or Off, and then press the OK button.
Printing Without Saving Jobs in the Common Box
Printing Without Saving Jobs in the Common Box
Jobs sent from a computer for which you have selected Print in Output Method (in Windows) or Send job to (in
Mac OS) in the printer driver are saved in the shared mailbox. (See "Using the Printer Hard Disk.") ➔ P.482
When Save: Common Box is Off in the Control Panel menu, print jobs for which you have selected Print in the
Output Method dialog box of the printer driver are deleted from the shared mailbox after printing.
Use this function when printing highly confidential documents.
1
On the Tab Selection screen of the Control Panel, press ◀ or ▶ to
select the Settings/Adj. tab ( ).
Note
• If the Tab Selection screen is not displayed, press the Menu button.
2 Press the OK button.
The Set./Adj. Menu is displayed.
Printing Without Saving Jobs in the Common Box iPF785
User's Guide
Print Job Management Advanced Print Job Operations
502

Canon imageprograf IPF785 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Storage media	HDD
Internal memory	256 MB
Internal storage capacity	320 GB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
