Format Dialog Box
Format Dialog Box
This dialog box appears when you select Format from the Object menu after you select an object.
Size Sheet
You can rotate, enlarge, or reduce an object.
Note
When the objects are not selected, you can not select Format.
Rotate
When you place a checkmark here, you can select Rotate Right or Rotate Left.
Setting Details
Rotate Right Rotates the object 90 degrees clockwise.
Rotate Left Rotates the object 90 degrees counterclockwise.
Note
When several objects are selected, you cannot select Rotate.
Enl./Red.
When you place a checkmark here, you can select
Scaling, Fit Paper Size, or Fit Photo Size.
Setting Details
Scaling Allows you to input the value of the enlargement or reduction ratio of an object.
Fit Paper Size Prints by enlarging or reducing each object to match the paper size. If you are using roll
paper, objects are enlarged or reduced so that the width of each object matches the width
of the roll paper.
Fit Photo Size Prints all of the objects at the specified photo size.
Note
You can input between 25 and 600.
You can change the numbers by clicking either button or button.
Format Dialog Box
iPF785
User's Guide
Windows Software Free Layout
188

Table of Contents

Other manuals for Canon imageprograf IPF785

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imageprograf IPF785 and is the answer not in the manual?

Canon imageprograf IPF785 Specifications

General IconGeneral
ColorYes
Printing colorsBlack, Cyan, Magenta, Matte black, Yellow
Print technologyInkjet
Maximum resolution2400 x 1200 DPI
Page description languagesGARO, HP-GL/2, HP-RTL
Media thickness0.07 - 0.8 mm
Maximum print size-
Media width (rolls)254 - 914.4 mm
Media width (sheets)203.2 - 914.4 mm
Maximum roll diameter150 mm
Paper tray media typesCoated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)A0, A1, A2, A3
ISO B-series sizes (B0...B9)B1, B2, B4
USB connectorUSB Type-A
USB 2.0 ports quantity1
Ethernet LAN data rates10/100/1000 Base-T/TX Mbit/s
Ethernet interface typeGigabit Ethernet
CertificationRoHS
Product colorBlack, Grey
Storage mediaHDD
Internal memory256 MB
Internal storage capacity320 GB
Sound pressure level (printing)48 dB
Compliance industry standardsIEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)0.5 W
Power consumption (typical)140 W
Storage temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)20 - 80 %
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth877 mm
Width1304 mm
Height1062 mm
