Canon imageprograf IPF785 User Manual

ColorSync
ColorSync
1
Check that ColorSync is selected in Matching Mode.
2 Place a checkmark on Soft Proof to simulate the output product in Layout Area.
Preferences Dialog Box
Preferences Dialog Box
This dialog box appears when you select Preferences from the imagePROGRAF Advanced Preview menu. You
can set the preferences for Free Layout.
•
Units
Set the unit for paper length, margins, and so on.
• Gridlines
You can input a grid line width value in numerical characters so that they serve as a guide to laying out ob-
jects.
Note
• You can input between 10.0 and 200.0(mm) (between 0.39 and 7.87(inch)).
• You can change the numbers by clicking either ▲ button or ▼ button.
ColorSync
iPF785
User's Guide
Mac OS Software Free Layout
302

Canon imageprograf IPF785 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Storage media	HDD
Internal memory	256 MB
Internal storage capacity	320 GB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
