Canon imageprograf IPF785 User Manual

3
Click Paper Settings from the imagePROGRAF
Print Plug-In toolbar/ribbon.
The Large-Format Printing Wizard dialog box is
displayed.
Important
• If you want to change the display to another file or application while the Large-Format Printing Wizard
is open, close the Large-Format Printing Wizard dialog box. Otherwise, you may not be able to change
displays or operate the toolbar/ribbon.
4 Click Portrait Orientation or Landscape Orientation.
Note
• The steps taken to create a Portrait Page Size will be used as an example to explain the procedure.
5 Adjust Length from the list-box or slide-bar.
6 Click the Create Page button.
7
ClickOK if the message is displayed.
iPF785 Portrait Orientation/Landscape Orientation(PowerPoint)
User's Guide
Windows Software Print Plug-In for O󱐰ce
239

Canon imageprograf IPF785 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Storage media	HDD
Internal memory	256 MB
Internal storage capacity	320 GB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
