4 Press ▲ or ▼ to select the type of paper, and then press the OK button.
5 Press ▲ or ▼ to select Width Detection, and then press the OK button.
6 Press ▲ or ▼ to select Off, and then press the OK button.
Load paper in the desired position to start printing from
Follow these instructions to load paper at the desired starting position for printing when Width Detection is Off.
1 If you did not send a print job in advance, a menu for selection of the type of paper is displayed.
Press ▲ or ▼ to select the type of paper, and then press the OK button.
Note
• If a print job was received before paper was advanced, the media type and size specified by the job are
shown on the Display Screen.
Thus, this screen is not displayed. Go to step 2.
2 "Width Detection OFF. OK to continue?" is now shown on the Display Screen. Press ▲ or ▼ to select
"Leave OFF", and then press the OK button.
3 After a menu for selection of the paper size is displayed, press ▲ or ▼ to select the paper size, and then
press the OK button.
4
Open the Top Cover and check the position where paper is
loaded.
To start printing from the current position, close the
Top Cover.
To reposition the paper, push the Release Lever
back.
iPF785 Printing From a Desired Starting Point
User's Guide
Handling and Use of Paper Handling sheets
361

Canon imageprograf IPF785 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Storage media	HDD
Internal memory	256 MB
Internal storage capacity	320 GB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
