Canon imageprograf IPF785 User Manual

2
In the Media Type list, select the name of the media
to switch off or on for display.
Click the Show/Hide button.
The selected paper is alternately shown or hidden.
Note
• You can select multiple paper.
• The names of media switched for non-display appear grayed out in the Media Type list.
• Each time you click the Show/Hide button, the display mode cycles from showing both the printer driver
and printer panel, to hiding both the printer driver and printer panel, and then to showing only the printer
panel.
3
In the Edit Media Types dialog box, click the Update
button.
4
The Confirm Update dialog box is displayed.
Configure Update Target and click the Execute but-
ton.
Communication with the printer begins.
Note
• You should normally select Update the printer control panel and printer driver.
Important
• When setting a data to the printer that differs from the data to be updated, the selected media informa-
tion file is updated. When you would like to remain the data that is set to the printer, click the Cancel
button.
• Do not attempt to print or turn the printer off while the program is communicating with the printer.
Switching Media Types Display Show/Hide iPF785
User's Guide
Handling and Use of Paper Media Conguration Tool (Mac OS)
394

Canon imageprograf IPF785 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.07 - 0.8 mm
Maximum print size	-
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 914.4 mm
Maximum roll diameter	150 mm
Paper tray media types	Coated paper, Cut sheet, Pre-Printed, Roll
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet LAN data rates	10/100/1000 Base-T/TX Mbit/s
Ethernet interface type	Gigabit Ethernet
Certification	RoHS
Product color	Black, Grey
Storage media	HDD
Internal memory	256 MB
Internal storage capacity	320 GB
Sound pressure level (printing)	48 dB
Compliance industry standards	IEEE 802.3ab, IEEE 802.3u, IEEE 802.3
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Storage temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth	877 mm
Width	1304 mm
Height	1062 mm
