Canon iPF710 - Page 125

Chapter 4
4-5
In attaching the upper cover, have the boss on damper [1] located on both sides into slit [2].
If the upper cover is not attached in correct position, it would slam shut without the damper being activated.
F-4-6
[1]
[2]
