Canon iPF710 - Ink Tank Unit

Chapter 4
4-23
4.3.11 Ink Tank Unit
0012-6377
a. Removing the ink tank unit
(1) Drain the printer of inks. See Disassembly/Reassembly > Point to Note on Disassembly and Reassembly
> Draining the Ink.
(2) Remove the joint between the ink tube unit and the ink tank unit.
(3) Remove the four screws[2], remove five connectors and two hooks[1], then remove the ink tank unit.
F-4-30
[1]
[2]
