Canon iPF710 - External Covers

Chapter 4
4-4
[3]Ink Tank Unit
See Disassembly/Reassembly > Tips on Disassembly/Reassembly > Ink Tank Unit.
F-4-4
4.3.4 External Covers
0012-6361
a. Upper cover
To detach the upper cover, detach damper cover [1] located on the left and right sides of the back each. Then,
fully open the upper cover and slide it to left.
F-4-5
[1]
[3]
[2]
[1]
