Canon iPF710 - Sample Printout

Chapter 7
7-27
7.1.4 Sample Printout
0017-5665
a) PRINTINF
A sample printout that is produced by executing [SERVICE MODE] > [DISPLAY] > [PRINTINF] is shown
below, along with instructions about how to interpret it.
F-7-1
xxxx PRINT INF
Firm:00.49 Boot:00.31 MIT(DBF):9303 MIT(DB):1.02 S/N:DF029090
SYSTEM
TYPE:DF029090 24 0 TMP:26 SIZE_LF: 0.0 SIZE_CR: 514.3
HEAD S/N:39410000
HEAD LOT:166L09A0
INK
C :0 M :0 Y :0 MBK :0MBK2 :0 BK :0
WARNING
01:0000 02:0000 03:0000 04:0000 05:0000
06:0000 07:0000 08:0000 09:0000 10:0000
11:0000 12:0000 13:0000 14:0000 15:0000
16:0000 17:0000 18:0000 19:0000 20:0000
ERROR
01:03060A00-2E01 02:0000 03:0000 04:0000 05:0000
06:0000 07:0000 08:0000 09:0000 10:0000
11:0000 12:0000 13:0000 14:0000 15:0000
16:0000 17:0000 18:0000 19:0000 20:0000
INK CHK: C:0 M:0 Y:0 MBK:0 MBK2:0 BK:0
COUNTER
PRINTER
LIFE TTL:0
LIFE ROLL:0 LIFE CUTSHEET:0 LIFE CASSETTE:0
LIFE A:0 B:0 C:0 D:0 E:0 F:0
MEDIA 7 MEDIA OTHER
NAME : NAME : OTHER
TTL : 0.0 m2 0.0 sq.f TTL : 0.0 m2 0.0 sq.f
ROLL : 0.0 m2 0.0 sq.f ROLL : 0.0 m2 0.0 sq.f
CUTSHEET : 0.0 m2 0.0 sq.f CUTSHEET : 0.0 m2 0.0 sq.f
CASSETTE : 0.0 m2 0.0 sq.f CASSETTE : 0.0 m2 0.0 sq.f
PARTS COUNTER
COUNTER A : OK 36
PARTS A1 : 0.0 36.1 0% 0.0
COUNTER B : OK 36
PARTS B1 : 0.0 64.0 0% 0.0
COUNTER D : OK 36
PARTS D1 1362 13028571 0% 1362
PARTS D2 : 377 6700000 0% 377
PARTS D3 : 2238 16500000 0% 2238
PARTS D4 : 33 60000 0% 33
COUNTER F : OK 36
PARTS F1 : 377 4000000 0% 377
COUNTER H : OK 36
PARTS H1 : 15 50000 0% 15
COUNTER L : OK 36
PARTS L1 : 4 12500 0% 4
COUNTER P : OK 36
PARTS P1 : 0 750 0% 0
COUNTER Q : OK 36
PARTS Q1 : 0 750 0% 0
COUNTER R : OK 36
PARTS R1 : 0 27500 0% 0
COUNTER V : OK 36
PARTS V1 : 0.0 15.2 0% 0.0
PV AUTO JUDGE : ON(NORMAL) , 1
(1)
(2)
(3)
(a) (b) (c) (d) (e) (f)
(4)
(a) (b)
