Canon iPF710 - Ink Tank; Printhead

Chapter 1
1-9
Operation panel LCD (160 X 128 dots), 12 keys, 5 LEDs
- Panel language
English
- Message language
English, German, French, Italian, Spanish, Chinese, Korean,
Russianand and Japanese
Printhead/Ink Tank type Printhead and separate ink tanks
Printhead [PF-03] Number nozzles: 2560 nozzles per color
Ink tank [PFI-102] MBK, BK, C, M, Y
Capacity: 130ml per color (Ink tanks supplied with the printer
contain 90ml of each color.)
Detection functions (Cover
system)
Head cap position sensor: Yes/ Cover open/closed sensor: Yes
Detection functions (Ink
passage system)
Ink tank sensor: Yes/Remaining ink level sensor: Yes/
Maintenance cartridge sensor: Yes/Used ink tank full sensor:
Yes/Printhead sensor: Yes
Detection functions
(Carriage system)
Paper slip sensor: Yes/Carriage position sensor: Yes/Carriage
home position sensor: Yes/Carriage cover open/closed sensor:
Yes/Carriage temperature sensor: Yes
Detection functions (Paper
path system)
Paper sensor: Yes/Leading and trailing paper end sensors: Yes/
Paper width sensor: Yes/Slant sensor: Yes/Paper release lever
position sensor: Yes/Roll media bottom sensor: Yes/
Remaining roll media sensor: Yes/Feed roller rotation sensor:
Yes
Operating noise Sound pressure level: 54dB (A) or less, operating; 35dB or less,
idle
Acoustic power level: 6.8 Bels
Operating environment Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80% without dew condensation
Print quality guaranteed
environment
Temperature: 15 to 30 degrees centigrade
Humidity: 10% to 80%RH
Power supply 100-240VAC (50/60Hz)
Power consumption
(Maximum)
140W or less
Power consumption When idle in energy save mode (sleep mode)
100-120V: 5W or less (When IEEE1394 board installed, 10W
or less)
220-240V: 6W or less (When IEEE1394 board installed, 11W
or less)
When switched off (idle):
1W or less
Printer unit dimensions
(WxDxH)
1507mm(width) x 871mm(depth) x 1094mm(height)
(including the stand)
Weight Approx. 64kg (including the stand)
