Canon iPF710 - Page 176

Chapter 6
6-13
T-6-22
J102
Pin
Number
Signal name IN/OUT Function
1 GND - GND
2 H1-D-DATA-7-OD_B OUT Odd head data signal 7(D)
3 GND - GND
4 H1-E-HE-8_B OUT Head heat enable signal 8(E)
5 GND - GND
6 H1-E-DATA-8-EV_B OUT Even head data signal 8(E)
7 GND - GND
8 H1-F-DATA-10-OD_B OUT Odd head data signal 10(F)
9 GND - GND
10 H1-E-DATA-9-OD_B OUT Odd head data signal 9(E)
11 GND - GND
12 H1-F-HE-10_B OUT Head heat enable signal 10(F)
13 GND - GND
14 H1-F-DATA-11-OD_B OUT Odd head data signal 11(F)
15 GND - GND
16 H1-F-HE-11_B OUT Head heat enable signal 11(F)
17 GND - GND
18 H1-F-DATA-11-EV_B OUT Even head data signal 11(F)
19 GND - GND
20 H1-F-DATA-10-EV_B OUT Even head data signal 10(F)
21 GND - GND
22 H1-E-HE-9_B OUT Head heat enable signal 9(E)
23 GND - GND
24 H1-E-DATA-9-EV_B OUT Even head data signal 9(E)
25 GND - GND
26 H1-B-DATA-2-OD_B OUT Odd head data signal 2(B)
27 GND - GND
28 H1-B-DATA-3-OD_B OUT Odd head data signal 3(B)
29 GND - GND
30 H1-C-HE-4_B OUT Head heat enable signal 4(C)
31 GND - GND
32 H1-C-DATA-4-OD_B OUT Odd head data signal 4(C)
33 GND - GND
34 H1-B-HE-2_B OUT Head heat enable signal 2(B)
35 GND - GND
36 H1-A-DATA-1-OD_B OUT Odd head data signal 1(A)
37 GND - GND
38 H1-A-DATA-0-OD_B OUT Odd head data signal 0(A)
39 GND - GND
