Canon iPF710 - Page 178

Chapter 6
6-15
T-6-24
24 H1-B-HE-3_B OUT Head heat enable signal 3(B)
25 GND - GND
26 H1-C-DATA-4-EV_B OUT Even head data signal 4(C)
27 GND - GND
28 H1-B-DATA-3-EV_B OUT Even head data signal 3(B)
29 GND - GND
30 H1-B-DATA-2-EV_B OUT Even head data signal 2(B)
31 GND - GND
32 H1-A-DATA-1-EV_B OUT Even head data signal 1(A)
33 GND - GND
34 H1-A-HE-1_B OUT Head heat enable signal 1(A)
35 GND - GND
36 H1-A-DATA-0-EV_B OUT Even head data signal 0(A)
37 GND - GND
38 H1-A-HE-0_B OUT Head heat enable signal 0(A)
39 GND - GND
40 /ENCODER_A IN Carriage encoder output signal A
41 /ENCODER_B IN Carriage encoder output signal B
42 H-DASH_LICC2_B OUT Head analogue switch A/D trigger signal
43 H1-DASLK_LICC2 OUT Head analogue switch clock signal
44 H1-DLD_LICC2 OUT Head analogue switch latch signal
45 H1-DATA_LICC2 OUT Head analogue switch data signal
46 H1-DSOUT2 IN Head temperature output signal 2
47 H1-DSOUT1 IN Head temperature output signal 1
48 IO_ASIC_SCL_B IN/OUT Head ROM control signal (clock)
49 IO_ASIC_SDA IN/OUT Head ROM control signal (data)
50 GND - GND
J201
Pin
Number
Signal name IN/OUT Function
1 /CRENCA IN Linear encoder output signal A
2 SNS5V OUT Power supply (+5V)
3 /CRENCB IN Linear encoder output signal B
4 GND - GND
5 N.C - N.C
J103
Pin
Number
Signal name IN/OUT Function
