Canon iPF710 - Page 184

Chapter 6
6-21
T-6-30
T-6-31
35 /H1-B-HE-3 IN Head heat enable signal 3(B)
36 H1-B-DATA-3-EV IN Even head data signal 3(B)
37 H1-B-DATA-2-EV IN Even head data signal 2(B)
38 /H1-A-HE-1 IN Head heat enable signal 1(A)
39 H1-A-DATA-1-EV IN Even head data signal 1(A)
40 H1-A-DATA-0-EV IN Even head data signal 0(A)
41 /H1-A-HE-0 IN Head heat enable signal 0(A)
42 H1-A-DATA-0-OD IN Odd head data signal 0(A)
43 H1-A-DATA-1-OD IN Odd head data signal 1(A)
44 /H1-B-HE-2 IN Head heat enable signal 2(B)
45 H1-B-DATA-2-OD IN Odd head data signal 2(B)
46 H1-B-DATA-3-OD IN Odd head data signal 3(B)
47 /H1-C-HE-4 IN Head heat enable signal 4(C)
48 H1-C-DATA-4-OD IN Odd head data signal 4(C)
49 MLT_SNS_1IN OUT Multi sensor signal 1
50 MLT_SNS_2IN OUT Multi sensor signal 2
J201
Pin Number Signal name IN/OUT Function
1 PWLED1 OUT Multi sensor LED1 drive signal
2 PWLED2 OUT Multi sensor LED2 drive signal
3 PWLED3 OUT Multi sensor LED3 drive signal
4 PWLED4 OUT Multi sensor LED4 drive signal
5 GND - GND
6 MLT_SNS_1 IN Multi sensor signal 1
7 MLT_SNS_2 IN Multi sensor signal 2
8 +5V OUT Power supply (+5V)
J601
Pin Number Signal name IN/OUT Function
1 VH2 OUT Power supply
2 VH2 OUT Power supply
3 VH2 OUT Power supply
4 VHT12 OUT Head transistor drive power supply
5 H1-F-DATA-10-EV OUT Even head data signal 10(F)
6 IO_ASIC_SDA IN/OUT Head ROM control signal (data)
7 IO_ASIC_SCL IN/OUT Head ROM control signal (clock)
J102
Pin Number Signal name IN/OUT Function
