Chapter 7
7-15
T-7-13
3) NOZZLE CHK POS.
This mode for adjusting the optical axis of the head management sensor. For details, refer to "Disassembly/
Reassembly" > "Adjustment and Setup Items" > "Procedure after replacing the head management sensor".
4) GAP CLIB.
This mode measures the gap between the printhead and media by multi sensor and corrects the calibration value.
5) CHANGE LF TYPE
Change the type of the feed roller.
0: Old feed roller
1: New feed roller
Display Description
MANUAL
HEAD ADJ
DETAIL Prints the detail patterns for the manual head adjustment.
After printing, the mode will change to [ADJ. SETTING]. Check the
printed patterns and input the set values.
BASIC Prints the basic patterns for the manual head adjustment.
After printing, the mode will change to [ADJ. SETTING]. Check the
printed patterns and input the set values.
ADJ.
SETTING
A to F A-1 to F-1 This mode is to input the registration adjustment values.
It is possible to return the values to the former one by printing the status
print before changing the value.
SAVE SETTINGS Save the registration adjustment values that has been input.
RESET SETTINGS Initialize the registration adjustment values (to 0).
