Chapter 2
2-27
Details of the cleaning function are shown in the table below.
Cleaning
mode
Name of Service mode or
PRINT INF
(Name of Main Menu)
Operation Description of cleaning
Cleaning 1 CLN-A-1/CLN-M-1
(Head Cleaning A)
Normal cleaning Removes dried ink from nozzles, thick ink
accumulated on the face, and paper particles.
Cleaning 2 CLN-A-2 Ink level adjustment and
cleaning
Adjust the ink level in the head by suction, and
then performs normal cleaning.
Cleaning 3 CLN-A-3 Initial filling ink Fills the empty tube (during initial installation)
with ink, and then performs normal cleaning.
Cleaning 4 CLN-M-4
(Replace P.head)
Ink drainage for head
replacement
Drains ink to replace the head (drains only the
ink in the head).
Cleaning 5 CLN-M-5
(Move Printer)
Ink drainage for secondary
transport
Drains ink from the head and tube for
secondary transport.
Cleaning 6 CLN-A-6/CLN-M-6
(Head Cleaning B)
Normal (strong) cleaning Performs suction stronger than when adjusting
the ink filling amount in the head or normal
cleaning to unclog nozzles.
Cleaning 7 CLN-A-7 Aging Performs idle ejection after replacement of the
head.
Cleaning 10 CLN-A-10
(Move Printer)
Ink filling after secondary
transport
Fills the empty tube (during installation after
secondary transport) with ink, and performs
normal cleaning.
Cleaning 11 CLN-A-11 Ink filling after head replacement Performs normal cleaning after head
replacement and ink filling.
Cleaning 15 CLN-A-15 Dot count suction Performs suction to remove ink adhered to
dried nozzles and thick ink accumulated on the
face when the dot count reaches the prescribed
value.
Cleaning 16 CLN-A-16 Precipitated ink agitation Performs the agitation (ink supply valve open/
close) operation to prevent the ink ingredient
from precipitating.
Cleaning 17 CLN-A-17 Cleaning (weak) Performs cleaning weaker than normal
cleaning to unclog nozzles.
To Next Page
