LASER CLASS 730i/720i/710 Chapter 4: Maintenance and Service
4-79
Figure 4-29 Sensor Tests
Pressing the 1 button
Pressing the 2 button
DS : Document sensor on/of
on/of: document/nop document
DES : Document edge sensor on/of
DOC : Document width sensor A4/B4
DFS : Document feed sensor on/of
CT1 : Cassette 1 recording paper sensor sensor on/of Registered paper size
CT2 : Cassette 2 recording paper sensor sensor on/of Registered paper size
CT3 : Cassette 3 recording paper sensor sensor on/of Registered paper size
MPT : MP tray recording paper sensor sensor on/of Registered paper size
CRG : Cartridge sensor on/of
TN : Toner sensor on/of
CVR : Cover sensor on/of
OVR : Recording paper eject over sensor on/of
FU : Face-up tray sensor on/of
JAM : Recording paper eject jam detection on/of
PANEL : One-touch cover sensor 1-4
6-3: SENSOR
[ 1] --- [ 4]
DS of DES of DOC B4
DFS of
CT1on LTR CT2on LGL
CT3of LTR MPTof
Pressing the 3 button
CRG on TN on CVR on
OVR of FU on JAM of
Pressing the 4 button
PANEL 1
