LASER CLASS 730i/720i/710 Chapter 4: Maintenance and Service
4-80
Pressing 1.
After the document is fed to the
stamp position and stamped five
times, it is ejected.
6-5: STAMP
[ 1] --- [ 2]
6-5: STAMP
5 point P.0020/00010
Pressing 2.
After the document is fed to the
stamp position and stamped
continue until the document sensor
becomes off.
6-5: STAMP
endless P.0020/00010
a-1) Toner sensor test check method
Use the following methods to test “TN on”, and “TN of”.
"TN on" check
(1) Open the printer cover.
(2) Insert a cartridge containing toner into the fax.
(3) Close the printer cover.
"TN of" check
(1) Open the printer cover.
(2) Insert the empty cartridge into the fax.
(3) Close the printer cover.
If the printer cover is closed without a cartridge being inserted, there will be
“TN on” display.
b) Stamp test
The stamp test is selected by pressing the numeric button 5 from the faculty test menu. In
this test, check if the stamp function operates correctly. The stamp test can test the
following 2 operations.
Figure 4-30 Stamp Test
NOTE
The above tests are carried out until the document sensor (DS) goes off.
