LASER CLASS 730i/720i/710 Chapter 5: Appendix
5-83
(5) Fasten the shield plate in place with the eight screws.
Figure 5-98 Network Kit III Installation 3
(6) Fasten the right cover in place with the two screws.
(7) Connect the modular cord (telephone line) to the fax (L1 jack).
Screws
Screws
Shield plate
