2-10
LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
5- 1 HB1-5330-000 1 COVER, REAR, RIGHT
2 XA9-1262-000 2 SCREW, M4X10
3 XB4-7401-209 4 SCREW, BINDING HEAD, SELF-TPG
4 XB6-7300-607 2 SCREW, TP, M3X6
5 NPN 1 CASSETTE FEEDER ASS’Y
