LASER CLASS 730i/720i/710 2.PARTS LAYOUT & PARTS LIST
FIGURE
&
KEY No.
PART No.
R
A
N
K
Q
T
Y
DESCRIPTION REMARKS
7- 1 NPN 1 READER ASS’Y
2 HG5-1840-000 1 SPEAKER UNIT
3 HG5-2814-000 1 OPERATION PANEL ASS’Y
4 XA9-1262-000 3 SCREW, M4X10
5 XB1-2300-807 17 SCREW, CROSS-RECESS, FCH
6 XB4-7402-009 3 SCREW, SELF-TAPPING, M4X20
7 XB6-7300-607 3 SCREW, TP, M3X6
8 NPN 1 PCL/NIC UNIT
