6-3
LASER CLASS 730i/720i/710 6.NUMERICAL INDEX
PART
NUMBER
FIGURE &
KEY No.
DESCRIPTION
PART
NUMBER
FIGURE &
KEY No.
DESCRIPTION
HT1-2203-000 47 - 3 SETUP GUIDE (ENGLISH)
HY9-0007-000 51 - T2 LUBE, MOLYKOTE EM-50L, GREASE
HY9-0022-000 51 - T3 IC-REMOVING TOOL (24-64P)
RB2-2836-000 14 - 1 LEVER, SENSOR
RB2-2837-000 14 - 2 SPRING, TORSION
RB2-2843-000 15 - 3 SPRING, TORSION
RB2-2892-000 27 - 1 ROLLER
29 - 5
39 - 1
RB2-2895-000 27 - 2 BUSHING, RIGHT
29 - 6
39 - 2
RB2-2896-000 27 - 3 BUSHING, LEFT
29 - 7
39 - 3
RB2-2897-000 27 - 4 BUSHING
RB2-2900-000 14 - 3 ROLLER, PICK-UP
RB2-2904-000 14 - 4 ROLLER
RB2-2926-000 15 - 4 BUSHING, TRANSFER, RIGHT
RB2-2973-000 26 - 1 BUSHING
RB2-2978-000 26 - 2 SPRING, COMPRESSION
RB2-3001-000 31 - 3 BODY, CASSETTE
RB2-3004-000 31 - 4 ARM, RELEASE, LEFT
RB2-3005-000 31 - 5 ARM, RELEASE, RIGHT
RB2-3007-000 31 - 6 SHEET, SEPARATION
41 - 3
RB2-3013-000 31 - 7 HOLDER, SEPARATION PAD
RB2-3036-000 11 - 5 TRAY, PAPER PICK-UP
RB2-3037-000 11 - 6 TRAY, SUB
RB2-3040-000 14 - 5 GEAR, 26T
RB2-3043-000 14 - 6 BUSHING, LEFT
RB2-3044-000 14 - 7 BUSHING, RIGHT
RB2-3046-000 27 - 5 ROLLER
RB2-3073-000 15 - 5 SHAFT, DRIVE, 1
RB2-3474-000 29 - 8 LEVER, SENSOR
RB2-3489-000 38 - 4 COVER, LOWER, LEFT
RB2-3490-000 29 - 9 ROLLER, FEED
RB2-6248-000 14 - 8 DAMPER, ASS’Y
RB2-6249-000 13 - 2 HINGE, FEED GUIDE
RB2-6264-000 15 - 6 ARM, SENSOR
RB2-6268-000 15 - 7 PULLEY
RB2-6269-000 15 - 8 SHAFT, DRIVE, FRONT
RB2-6270-000 15 - 9 BELT, PAPER FEED, 3
RB2-6272-000 15 - 10 BELT, PAPER FEED, 1
RB2-6273-000 15 - 11 BELT, PAPER FEED, 2
RB2-6274-000 15 - 12 SHAFT, DRIVE, REAR
RB2-6285-000 11 - 9 GUIDE, PAPER REAR
RB2-6287-000 11 - 10 TRAY, FACE-UP
RB2-6288-000 11 - 11 ROLLER, GUIDE
RB2-6289-000 11 - 12 SPRING, TORSION
RB2-6297-000 28 - 5 FOOT, RUBBER
38 - 5
RB2-6302-000 27 - 6 ROLLER, FEED
RB2-6304-000 27 - 7 ROLLER, PAPER PICK-UP
29 - 10
39 - 4
RB2-6310-000 27 - 8 ARM, PAPER SENSOR
RB2-6314-000 27 - 9 SPRING, TENSION
RB2-6318-000 27 - 10 ROLLER, FEED
RB2-6321-000 27 - 11 SPRING, TORSION
RB2-6349-000 31 - 8 PAD, SEPARATION
RB2-6351-000 26 - 3 LEVER, DELIVERY
RB2-6357-000 26 - 4 GUIDE, ENTRANCE
RB2-6368-000 26 - 5 ROLLER, PRESSURE
RB2-6372-000 26 - 6 ROLLER, DELIVERY
RB2-6374-000 26 - 7 ROLLER, DELIVERY
RB2-6405-000 11 - 7 HINGE, LEFT
RB2-6406-000 11 - 8 HINGE, RIGHT
RB2-6448-000 39 - 5 ARM, SENSOR
RB2-6453-000 38 - 6 COVER, SENSOR
RB2-6458-000 41 - 4 BODY, CASSETTE
RB2-6459-000 41 - 5 ARM, PAD
RB2-6463-000 41 - 6 COVER, RIGHT EDGE
RB2-6464-000 41 - 7 COVER, LEFT EDGE
RB2-6467-000 41 - 8 COVER, REAR EDGE
RB2-6469-000 41 - 9 PLATE, END
RB2-6471-000 41 - 10 GEAR, 20T
RB2-6474-000 41 - 11 PAD, SEPARATION
RF5-2609-000 26 - 8 HOLDER, CONTACT
RF5-3272-000 14 - 9 PAD, SEPARATION
RF5-3279-000 35 - 3 HOLDER, SENSOR LEVER
RF5-3304-000 40 - 1 GEAR, 31T/26T
RG5-4128-000 14 - 10 MP PICK-UP ASS’Y
RG5-4156-000 14 - 11 CASSETTE PICK-UP GEAR ASS’Y
RG5-4394-000 38 - 7 LOWER FEED ROLLER ASS’Y
RG5-5542-000 12 - 21 FD DELIVERY ROLLER ASS’Y
RG5-5548-000 12 - 6 REVERSE GUIDE ASS’Y
RG5-5550-000 15 - 13 TRANSFER ROLLER ASS’Y
RG5-5551-000 14 - 12 CASSETTE PAPER PICK-UP ASS’Y
RG5-5552-000 12 - 7 DUPLEX SOLENOID ASS’Y
RG5-5553-000 13 - 3 POSITION GUIDE ASS’Y
RG5-5554-000 13 - 4 DUPLEX FEED GUIDE ASS’Y
RG5-5559-000 12 - 8 FIXING ASS’Y
RG5-5560-070 26 - 9 FIXING FILM ASS’Y
RG5-5561-000 26 - 10 UPPER DELIVERY GUIDE ASS’Y
RG5-5576-000 11 - 13 MULTI-PURPOSE TRAY ASS’Y
RG5-5577-000 15 - 14 GEAR ASS’Y
RG5-5621-000 39 - 6 FEED ROLLER ASS’Y
RG5-5626-000 41 - 12 LEFT SIDE PLATE ASS’Y
RG5-5627-000 41 - 13 RIGHT SIDE PLATE ASS’Y
RG5-5630-000 40 - 2 PAPER FEEDER DRIVER PCB ASS’Y
RH2-5427-000 12 - 9 FLAT CABLE, LASER
RH7-1461-000 25 - 1 MOTOR, DC 23V
RH7-1463-000 11 - 15 FAN
RH7-5213-000 30 - 4 SOLENOID
RH7-5270-000 12 - 10 SOLENOID
