6-4
LASER CLASS 730i/720i/710 6.NUMERICAL INDEX
PART
NUMBER
FIGURE &
KEY No.
DESCRIPTION
PART
NUMBER
FIGURE &
KEY No.
DESCRIPTION
RH7-5273-000 12 - 11 SOLENOID
RH7-5276-000 40 - 3 SOLENOID
RH7-6051-000 12 - 12 MICROSWITCH
RS6-0441-000 12 - 13 GEAR, 15T
RS6-0445-000 14 - 13 GEAR, 14T
RS6-0464-000 15 - 15 GEAR, 20T
RS6-0501-000 29 - 11 GEAR, 15T
RS6-0906-000 27 - 12 GEAR, 15T
RS6-0907-000 27 - 13 GEAR, 24T
RS6-0921-000 26 - 11 GEAR, 14T
RS6-0922-000 26 - 12 GEAR, 16T
RS6-0923-000 26 - 13 GEAR, 27T
RS6-2020-000 31 - 9 SPRING, COMPRESSION
RS6-2021-000 31 - 10 SPRING, COMPRESSION
RS6-2022-000 15 - 16 SPRING, COMPRESSION
RS6-2025-000 14 - 14 SPRING, TENSION
RS6-2030-000 11 - 16 SPRING, TENSION
RS6-2035-000 31 - 11 SPRING, COMPRESSION
RS6-2061-000 40 - 4 SPRING, TENSION
RS6-2375-000 12 - 14 SPRING, COMPRESSION
RS6-2395-000 41 - 14 SPRING, COMPRESSION
RS6-2396-000 41 - 15 SPRING, COMPRESSION
RS6-2397-000 40 - 5 SPRING, TENSION
RS6-2398-000 39 - 8 SPRING, COMPRESSION
VS1-6173-006 28 - 6 CONNECTOR, 6P
VS1-6174-006 39 - 9 CONNECTOR, 6P
VS1-6174-012 29 - 12 CONNECTOR, 12P
VT2-0013-080 9 - 15 SUPPORT, PCB
49 - 6
WE8-5305-000 9 - 16 FERRITE, CORE
47 - 6
WG8-5362-000 22 - 12 PHOTO-INTERRUPTER, TLP1241
WG8-5364-000 14 - 15 IC,PHOTO-INTERRUPTER,GP1SQ73P
15 - 17
25 - 2
27 - 14
39 - 10
WG8-5382-000 26 - 14 PHOTO INTERRUPTER TLP1242
29 - 13
WK1-5047-000 32 - BAT1 LITHIUM BATTERY, CR2450HC22NC
WK1-5101-000 32 - BAT2 LITHIUM BATTERY, VL2330/G1A
WS1-5397-000 32 - 1 PLUG, JUMPER
45 - 3
WT2-5737-000 47 - 7 CLIP, CABLE
49 - 7
XA9-0429-000 43 - 4 SCREW (W)
XA9-0476-000 20 - 17 SCREW, TP M3X8
XA9-0606-000 38 - 8 SCREW, M4X10
39 - 11
41 - 16
XA9-0836-000 40 - 6 SCREW, TP, M3X6
XA9-0924-000 29 - 14 SCREW, W/WASHER, M3X8
XA9-1223-000 26 - 15 SCREW, TP, M3X6
XA9-1226-000 26 - 16 SCREW, W/WASHER, M3X8
35 - 4
40 - 7
XA9-1262-000 3 - 3 SCREW, M4X10
4-3
5-2
6-4
7-4
10 - 4
11 - 17
12 - 15
13 - 5
14 - 16
15 - 18
XA9-1273-000 12 - 16 SCREW, TP, M4X12
XA9-1292-000 12 - 17 SCREW, M4X14
XA9-1316-000 38 - 9 SCREW, TP, M4X10
XB1-1300-607 36 - 4 SCREW, PH3X10 (S)
48 - 3
XB1-2300-407 48 - 4 SCREW, BH3X4 (S)
XB1-2300-605 25 - 3 SCREW, MACHINE M3X6
XB1-2300-807 6 - 5 SCREW, CROSS-RECESS, FCH
7-5
8-7
9-7
10 - 5
18 - 2
20 - 18
21 - 16
22 - 14
36 - 5
44 - 8
45 - 4
47 - 8
48 - 5
49 - 8
XB2-7300-607 8 - 8 SCREW, M3X6
9-8
10 - 6
11 - 18
12 - 18
XB2-7400-607 29 - 15 SCREW, TOOTHED WASHER, M4X6
39 - 12
XB4-7300-607 46 - 2 SCREW, TAP TIGHT, BINDING HEAD
XB4-7300-807 8 - 9 SCREW, TAP TIGHT, BINDING HEAD
9-9
17 - 8
20 - 19
21 - 17
22 - 13
23 - 10
44 - 9
XB4-7301-207 43 - 5 SCREW, BH M3X12, S
