Canon Oce PlotWave 450 - The Media Drawer

The media drawer
1
2
3
4
6
5
Component - function table
No. Component Description / Function
1 [media drawer] Media drawer that contains media roll 1 and 2. Optional
media drawer below contains media roll 3 and 4.
2 [roll holder] Carries the media roll
3 [media roll] 1 Media placed on roll holder in first position.
4 [media roll] 2 Media placed on roll holder in second position.
5 [roll loading station] Groove integrated behind the front cover of the media
drawer, on which the media can be easily loaded.
6 [clean cut button] Button used to trim a strip of a new or damaged media
roll.
The media drawer
28
Chapter 2 - Get to Know the Printing System
