- 47 -
Section 8: Basic Specification
1 Printing Method
Image Area : Dye Diffusion Thermal Transfer
Character Area : Molten Type Thermal Transfer
Protective Layer : Molten Type Thermal Transfer system
2 Printing Media
PVC Card (Conforms to ISO 7810 , JIS X6301 )or made of other materials
with receivable layer on the surface
Size : 54.5mm x 85.5mm
Thickness : 0.76 +- 10% mm
3 Printing Resolution 300 dpi (11.81 dots/mm)
4 Printing Grayscale
Input : 256 grayscale for each of colors R, G and B
Output : 256 grayscale control for each of colors Y, M and C
5 Printing Size Max. 85.5mm(card longitudinal direction)
x 54.5mm(card transverse direction)
6 Printing Speed 28 seconds / one side. (excluding communication time.) at whole area printing
at the size as shown above.
7 Ink Ribbon Standard: 3BP 5 panels (250images)
: BK/OP 2 panels (250images)
8 Flip Turn Feature Standard
9 Supply method
and capacity
100 cards(at card thickness :0.76mm) ; supplied automatically
10 Interface USB2.0
Ethernet 100BASE-TX (Operation guaranteed)
11 Power supply
AC 100～240V 50/60Hz
12 Power consumption 120W max.
13 Equipment
dimensions
421mm(H) × 270mm(W) × 331mm(D)
(excluding Stack Box)
14 Equipment weight 13kg : Main body
15 Option
Encoder
Device code IC encoding Magnetic encoding specification
MD No ISO (Hi-Co, Lo-Co switchable)
