Canon VB-C500VD - Name and Function of each Part

1-18
Notes on Operating Environment
Name and Function of Each Part
Dome Case/Inner Cover/Camera Interior
(1) Dome case
(2) Inner cover
(3) Varifocal lens
Horizontal viewing angle 82°
(4) Focus lock screw
(5) Zoom adjustment knob
(6) Rotation lock screw
(7) Pan lock screw
(8) Tilt lock screw
(9) Dome case lock screw
VB
-
C500VD VB
-
C500D
(3)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(1)
(4)
(5)
(6)
(7)
(8)
(1)
(2)(2)
(9)
