Before Use
Optional Items
Purchase optional items separately as necessary.
Audio Interface Cable WA500-VB
Use this interface cable (UL VW-1 Cable) to connect the camera to an audio input/output device
(speaker, microphone, etc.).
The long end (has cable marker) from the bifurcation point in the cable corresponds to the audio
output terminal. The short end (does not have cable marker) from the bifurcation point in the
cable corresponds to the audio input terminal.
For details, see "Audio Input/Output Terminals" ( P. 3-8).
OUT
IN
Cable marker
