Canton Smart Sounddeck 100 User Manual

38
English
• Bluetooth [BT]
– BT Pairing [BTP]
– BT Select [BTS]
– BT Reset [BRE]
– Autoplay [ATP]
Wireless Pairing [WSP]
The Sounddeck 100 offers you the ability to connect (wireless-)speaker from the Canton Smart Series wirelessly to a build multichannel home
cinema system with a range of possibilities. With the build-in audio wireless module you can, for example, connect two surround speakers
and/or two Dolby Atmos
®
ceiling speakers. It is also possible to use the Sounddeck 100 as center speaker with two additional front speakers.
With the wireless module you can upgrade the Sounddeck 100 to a full 5.1.2 home cinema system.
The pairing of wireless speakers is made in the Wireless Pairing [WSP] menu. In such a wireless speaker setup, the Sounddeck is always the
“master speaker”, other speakers will be defined as “slave speakers”.
Caution: Before starting the pairing process, the speaker to be paired (slave speaker) must have been disconnected from the mains for at least
30 seconds.
For pairing slave speakers, proceed as follows:
1
To enter the menu, press the "M" button.
2
Use the " " or " " button to navigate to the menu Wireless Setup [WIS] and confirm with the "OK" button.
3
Confirm the first menu item Wireless Pairing [WSP] by pressing the "OK" button.
4
Front Left [FL] is selected. Please confirm the front left speaker or use the " " or " " buttons to select the speaker you want to pair and
confirm with "OK".
The following speakers are selectable:
• Front Left and Front Right: The paired front speakers will play the front left and right channel of a multichannel signal and the
Sounddeck will play the center channel. In playmode Stereo only the two front speakers will play.
• Surr. Left and Surr. Right: The paired surround speakers will play the surround channels of a multichannel signal, instead of being
played as virtual speakers from the Sounddeck or the front speakers.
• Top Left and Top Right: The paired Top speakers will play Dolby Atmos
®
signals instead of being played as virtual speakers from the
Sounddeck or the front speakers.

Canton Smart Sounddeck 100 Specifications

General

Audio decoders	Dolby Atmos
RMS rated power	- W
Audio output channels	- channels
Audio Return Channel (ARC)	Yes
Wi-Fi	-
HDCP version	2.2
HDMI ports quantity	4
Connectivity technology	Wired
Product color	Black
Wall mountable	No
Audio formats supported	DTS

Weight and Dimensions

Width	- mm
Soundbar weight	- g
