Carel kVent User Manual

kVent – rel 3.1 – 22/06/2018
39
- Digital input functions - Priority USInt R DI_ReadFnt[11].Prio IR396 PIV396
- Digital input functions - Status Bool R DI_ReadFnt[11].Hw_Val DI261 BV1761
Gb21 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[11].Ch HR930 IV930
Gb22 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[11].Logic C284 BV1763
- Digital input functions - Priority USInt R DI_ReadFnt[12].Prio IR397 PIV397
- Digital input functions - Status Bool R DI_ReadFnt[12].Hw_Val DI262 BV1765
Gb23 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[12].Ch HR932 IV932
Gb24 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[12].Logic C285 BV1767
- Digital input functions - Priority USInt R DI_ReadFnt[13].Prio IR398 PIV398
- Digital input functions - Status Bool R DI_ReadFnt[13].Hw_Val DI263 BV1769
Gb25 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[13].Ch HR934 IV934
Gb26 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[13].Logic C286 BV1771
- Digital input functions - Priority USInt R DI_ReadFnt[14].Prio IR399 PIV399
- Digital input functions - Status Bool R DI_ReadFnt[14].Hw_Val DI264 BV1773
Gb27 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[14].Ch HR936 IV936
Gb28 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[14].Logic C287 BV1775
- Digital input functions - Priority USInt R DI_ReadFnt[15].Prio IR400 PIV400
- Digital input functions - Status Bool R DI_ReadFnt[15].Hw_Val DI265 BV1777
Gb29 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[15].Ch HR938 IV938
Gb30 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[15].Logic C288 BV1779
- Digital input functions - Priority USInt R DI_ReadFnt[16].Prio IR401 PIV401
- Digital input functions - Status Bool R DI_ReadFnt[16].Hw_Val DI266 BV1781
Gb31 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[16].Ch HR940 IV940
Gb32 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[16].Logic C289 BV1783
- Digital input functions - Priority USInt R DI_ReadFnt[17].Prio IR402 PIV402
- Digital input functions - Status Bool R DI_ReadFnt[17].Hw_Val DI267 BV1785
Gb33 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[17].Ch HR942 IV942
Gb34 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[17].Logic C290 BV1787
- Digital input functions - Priority USInt R DI_ReadFnt[18].Prio IR403 PIV403
- Digital input functions - Status Bool R DI_ReadFnt[18].Hw_Val DI268 BV1789
Gb35 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[18].Ch HR944 IV944
Gb36 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[18].Logic C291 BV1791
- Digital input functions - Priority USInt R DI_ReadFnt[19].Prio IR404 PIV404
- Digital input functions - Status Bool R DI_ReadFnt[19].Hw_Val DI269 BV1793
Gb37 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[19].Ch HR946 IV946
Gb38 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[19].Logic C292 BV1795
- Digital input functions - Priority USInt R DI_ReadFnt[20].Prio IR405 PIV405
- Digital input functions - Status Bool R DI_ReadFnt[20].Hw_Val DI270 BV1797
Gb39 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[20].Ch HR948 IV948
Gb40 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[20].Logic C293 BV1799
- Digital input functions - Priority USInt R DI_ReadFnt[21].Prio IR406 PIV406
- Digital input functions - Status Bool R DI_ReadFnt[21].Hw_Val DI271 BV1801
Gb41 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[21].Ch HR950 IV950
Gb42 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[21].Logic C294 BV1803
- Digital input functions - Priority USInt R DI_ReadFnt[22].Prio IR407 PIV407
- Digital input functions - Status Bool R DI_ReadFnt[22].Hw_Val DI272 BV1805
Gb43 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[22].Ch HR952 IV952
Gb44 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[22].Logic C295 BV1807
- Digital input functions - Priority USInt R DI_ReadFnt[22].Prio IR407 PIV407
- Digital input functions - Status Bool R DI_ReadFnt[23].Hw_Val DI273 BV1808
Gb45 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[23].Ch HR954 IV954
Gb46 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[23].Logic C296 BV1810
Gb47 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[24].Ch HR1086 IV1453
Gb48 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[24].Logic C350 BV1454
DIGITAL OUT SET menu 6.10.3
Mask
code
Description
Type
Default
UoM
Range
R/W
Variable Name
BMS
BacNet
- Digital output functions - Priority USInt R DO_ReadFnt[1].Prio IR408 PIV408
- Digital output functions - Status Bool R DO_ReadFnt[1].Hw_Val DI274 BV1812
Gc01 Digital output functions - Channel DInt 0 0...50 R/W DO_ReadFnt[1].Ch HR956 IV956
Gc02 Digital output functions - Logic Bool FALSE 0...1 R/W DO_ReadFnt[1].Logic C297 BV1814
- Digital output functions - Priority USInt R DO_ReadFnt[2].Prio IR409 PIV409
- Digital output functions - Status Bool R DO_ReadFnt[2].Hw_Val DI275 BV1816
Gc03 Digital output functions - Channel DInt 0 0...50 R/W DO_ReadFnt[2].Ch HR958 IV958
Gc04 Digital output functions - Logic Bool FALSE 0...1 R/W DO_ReadFnt[2].Logic C298 BV1818
- Digital output functions - Priority USInt R DO_ReadFnt[3].Prio IR410 PIV410
- Digital output functions - Status Bool R DO_ReadFnt[3].Hw_Val DI276 BV1820
Gc05 Digital output functions - Channel DInt 0 0...50 R/W DO_ReadFnt[3].Ch HR960 IV960
Gc06 Digital output functions - Logic Bool FALSE 0...1 R/W DO_ReadFnt[3].Logic C299 BV1822
- Digital output functions - Priority USInt R DO_ReadFnt[4].Prio IR411 PIV411
- Digital output functions - Status Bool R DO_ReadFnt[4].Hw_Val DI277 BV1824
Gc07 Digital output functions - Channel DInt 0 0...50 R/W DO_ReadFnt[4].Ch HR962 IV962
Gc08 Digital output functions - Logic Bool FALSE 0...1 R/W DO_ReadFnt[4].Logic C300 BV1826
- Digital output functions - Priority USInt R DO_ReadFnt[5].Prio IR412 PIV412
- Digital output functions - Status Bool R DO_ReadFnt[5].Hw_Val DI278 BV1828
Gc09 Digital output functions - Channel DInt 0 0...50 R/W DO_ReadFnt[5].Ch HR964 IV964
Gc10 Digital output functions - Logic Bool FALSE 0...1 R/W DO_ReadFnt[5].Logic C301 BV1830
