Carel kVent User Manual

kVent – rel 3.1 – 22/06/2018
38
- Analog input functions - Hardware value Real °C R AI_ReadFnt[21].Read.Hw_Val IR377 AV377
GaA1 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[21].Ch HR880 IV880
GaA2 Analog input functions - Type USInt
0
0...50 R/W AI_ReadFnt[21].Param.Typ HR882 PIV882
GaA3 Analog input functions - Minimum value Real
-50.0
°C -999.9...999.9 R/W AI_ReadFnt[21].Param.Min_Val HR883 AV883
GaA4 Analog input functions - Maximum value Real
105.0
°C -999.9...999.9 R/W AI_ReadFnt[21].Param.Max_Val HR884 AV884
GaA5 Analog input functions - Offset Real
0.0
°K -99.9...99.9 R/W AI_ReadFnt[21].Param.Offset HR885 AV885
- Analog input functions - Priority USInt R AI_ReadFnt[22].Prio IR378 PIV378
- Analog input functions - Hardware value Real bar R AI_ReadFnt[22].Read.Hw_Val IR379 AV379
GaA6 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[22].Ch HR886 IV886
GaA7 Analog input functions - Type USInt
43
0...50 R/W AI_ReadFnt[22].Param.Typ HR888 PIV888
GaA8 Analog input functions - Minimum value Real
0.0
bar -9999.9...9999.9 R/W AI_ReadFnt[22].Param.Min_Val HR889 AV889
GaA9 Analog input functions - Maximum value Real
17.3
bar -9999.9...9999.9 R/W AI_ReadFnt[22].Param.Max_Val HR890 AV890
GaB0 Analog input functions - Offset Real
0.0
bar -99.9...99.9 R/W AI_ReadFnt[22].Param.Offset HR891 AV891
- Analog input functions - Priority USInt R AI_ReadFnt[23].Prio IR380 PIV380
- Analog input functions - Hardware value Real °C R AI_ReadFnt[23].Read.Hw_Val IR381 AV381
GaB1 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[23].Ch HR892 IV892
GaB2 Analog input functions - Type USInt
0
0...50 R/W AI_ReadFnt[23].Param.Typ HR894 PIV894
GaB3 Analog input functions - Minimum value Real
-50.0
°C -999.9...999.9 R/W AI_ReadFnt[23].Param.Min_Val HR895 AV895
GaB4 Analog input functions - Maximum value Real
105.0
°C -999.9...999.9 R/W AI_ReadFnt[23].Param.Max_Val HR896 AV896
GaB5 Analog input functions - Offset Real
0.0
°K -99.9...99.9 R/W AI_ReadFnt[23].Param.Offset HR897 AV897
- Analog input functions - Priority USInt R AI_ReadFnt[24].Prio IR382 PIV382
- Analog input functions - Hardware value Real % R AI_ReadFnt[24].Read.Hw_Val IR383 AV383
GaB6 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[24].Ch HR898 IV898
GaB7 Analog input functions - Type USInt
43
0...50 R/W AI_ReadFnt[24].Param.Typ HR900 PIV900
GaB8 Analog input functions - Minimum value Real
0.0
% -999.9...999.9 R/W AI_ReadFnt[24].Param.Min_Val HR901 AV901
GaB9 Analog input functions - Maximum value Real
100.0
% -999.9...999.9 R/W AI_ReadFnt[24].Param.Max_Val HR902 AV902
GaC0 Analog input functions - Offset Real
0.0
% -99.9...99.9 R/W AI_ReadFnt[24].Param.Offset HR903 AV903
- Analog input functions - Priority USInt R AI_ReadFnt[25].Prio IR384 PIV384
- Analog input functions - Hardware value Real %rh R AI_ReadFnt[25].Read.Hw_Val IR385 AV385
GaC1 Analog input functions - Channel DInt
0
0...70 R/W AI_ReadFnt[25].Ch HR904 IV904
GaC2 Analog input functions - Type USInt
43
0...50 R/W AI_ReadFnt[25].Param.Typ HR906 PIV906
GaC3 Analog input functions - Minimum value Real
0.0
%rh -999.9...999.9 R/W AI_ReadFnt[25].Param.Min_Val HR907 AV907
GaC4 Analog input functions - Maximum value Real
100.0
%rh -999.9...999.9 R/W AI_ReadFnt[25].Param.Max_Val HR908 AV908
GaC5 Analog input functions - Offset Real
0.0
%rh -99.9...99.9 R/W AI_ReadFnt[25].Param.Offset HR909 AV909
DIGITAL IN SET menu 6.10.2
Mask
code
Description
Type
Default
UoM
Range
R/W
Variable Name
BMS
BacNet
- Digital input functions - Priority USInt R DI_ReadFnt[1].Prio IR386 PIV386
- Digital input functions - Status Bool R DI_ReadFnt[1].Hw_Val DI251 BV1721
Gb01 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[1].Ch HR910 IV910
Gb02 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[1].Logic C274 BV1723
- Digital input functions - Priority USInt R DI_ReadFnt[2].Prio IR387 PIV387
- Digital input functions - Status Bool R DI_ReadFnt[2].Hw_Val DI252 BV1725
Gb03 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[2].Ch HR912 IV912
Gb04 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[2].Logic C275 BV1727
- Digital input functions - Priority USInt R DI_ReadFnt[3].Prio IR388 PIV388
- Digital input functions - Status Bool R DI_ReadFnt[3].Hw_Val DI253 BV1729
Gb05 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[3].Ch HR914 IV914
Gb06 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[3].Logic C276 BV1731
- Digital input functions - Priority USInt R DI_ReadFnt[4].Prio IR389 PIV389
- Digital input functions - Status Bool R DI_ReadFnt[4].Hw_Val DI254 BV1733
Gb07 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[4].Ch HR916 IV916
Gb08 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[4].Logic C277 BV1735
- Digital input functions - Priority USInt R DI_ReadFnt[5].Prio IR390 PIV390
- Digital input functions - Status Bool R DI_ReadFnt[5].Hw_Val DI255 BV1737
Gb09 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[5].Ch HR918 IV918
Gb10 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[5].Logic C278 BV1739
- Digital input functions - Priority USInt R DI_ReadFnt[6].Prio IR391 PIV391
- Digital input functions - Status Bool R DI_ReadFnt[6].Hw_Val DI256 BV1741
Gb11 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[6].Ch HR920 IV920
Gb12 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[6].Logic C279 BV1743
- Digital input functions - Priority USInt R DI_ReadFnt[7].Prio IR392 PIV392
- Digital input functions - Status Bool R DI_ReadFnt[7].Hw_Val DI257 BV1745
Gb13 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[7].Ch HR922 IV922
Gb14 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[7].Logic C280 BV1747
- Digital input functions - Priority USInt R DI_ReadFnt[8].Prio IR393 PIV393
- Digital input functions - Status Bool R DI_ReadFnt[8].Hw_Val DI258 BV1749
Gb15 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[8].Ch HR924 IV924
Gb16 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[8].Logic C281 BV1751
- Digital input functions - Priority USInt R DI_ReadFnt[9].Prio IR394 PIV394
- Digital input functions - Status Bool R DI_ReadFnt[9].Hw_Val DI259 BV1753
Gb17 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[9].Ch HR926 IV926
Gb18 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[9].Logic C282 BV1755
- Digital input functions - Priority USInt R DI_ReadFnt[10].Prio IR395 PIV395
- Digital input functions - Status Bool R DI_ReadFnt[10].Hw_Val DI260 BV1757
Gb19 Digital input functions - Channel DInt
0
0...70 R/W DI_ReadFnt[10].Ch HR928 IV928
Gb20 Digital input functions - Logic Bool
FALSE
0...1 R/W DI_ReadFnt[10].Logic C283 BV1759
