45
ENG
pCO5plus +0300020EN rel. 1.2 - 07.11.2013
Slave
USB
(Device)
Display
terminal
Protocol active on
pCO5+
NOTES
Connector J9
PST terminal Incompatible with CAREL Master 5 expansions
Local terminal or pLAN
Local terminal or pLAN With Local Terminal the pGD* works in pCOT emulation mode
Local terminal or pLAN
pLAN
pLAN or CAREL Master
or CAREL Master 5
expansions
Can be activated only on one serial port. CAREL Master 5 expansions: incompatible with PST terminal
CAREL Master or CAREL
Master 5 expansions
Can be activated only on one serial port. CAREL Master 5 expansions: incompatible with PST terminal. If the
protocol is activated, other devices cannot be supervised on J23.
CAREL Master or CAREL
Master 5 expansions
CAREL Master: can be activated either on BMS or Fieldbus serial port.
Can be activated either on pLAN or Fieldbus serial port. When activated on Fieldbus serial port, the protocol is
deactivated on connector J23.
CAREL Master 5 expansions Can be activated only on one serial port; incompatible with PST terminal
CAREL Master Can be activated only on one serial port
CAREL Slave Can be activated only on one serial port at a time, except for BMS and Fieldbus serial ports on which at can be
activated simultaneously. If active on pLAN serial port, protocols PSTN, GSM, Modbus Slave and CAREL Slave
cannot be used on BMS serial port.
Modbus slave extended
with pCOweb
Modbus slave extended only for pCOWEB serial card with FW version >= 1.4
Modbus Slave If Modbus Slave is active then CAREL Slave can be activated only on another serial port. The second Modbus
extended on BMS2 (with 10000 integer variables) can work at the same time as the one activated on the other
ports.
Modbus Master Can be activated on two serial ports at the same time (provided they are diff erent and have separate management
lists) by selecting the second Modbus Master.
Modbus Master - Benshaw Maximum two Benshaw devices (addresses 1 and 2).
x WinLoad Can be activated only on one serial port; on Fieldbus serial from BIOS 4.00
PSTN Can be activated only on one serial port
Incompatible with PSTN protocol; if activated on BMS serial port, is incompatible with CAREL Slave set on pLAN
serial port.
GSM
Can be activated only on one serial port at a time.
Incompatible with PSTN protocol; if activated on BMS serial port, is incompatible with CAREL Slave set on pLAN
serial port
MP-Bus Maximum 8 devices
Serial printer Can be activated only on one serial port
Pendrive USB master and USB slave port cannot be used at the same time
Mbus master for th-Tune Can be activated on pLAN or Fieldbus serial port, but not on both at the same time
2
nd
Modbus slave
extended on BMS2
Version for 2048D (coil), 5000A, 10000l (15000 registers)
