7.1 Devices that can be connected to the
pCO5+
device serial
ZERO -
pLAN
serial ONE - BMS1 serial TWO – Fieldbus 1 serial
THREE
- BMS 2
serial
FOUR -
Fieldbus 2
master (Host)
USB
Connector J11 Connector J10 PCO1004850 PCOS004850 PCO100MDM0 PCO10000F0 PCO10000R0 PCO10W0WB0 PCO10W0BA0 PCOS00HBB0 PCOS00KXB0 PCO100FD10 PCOS00FD20 PCO100TLN0 PCO100MPB0 PCOS00HBF0 Connector J25 Connector J26 (and J23 on L and XL)
PST terminal x
PLD terminal x
pCOT - pCOI terminal x
pGD0 - pGD1 terminal x
pGD2 - pGD3 terminal x
Aria terminal x
pCO in pLAN x
FCM series controllers x
EVD200 x
EVD Evolution x x
CAREL slave devices (tLAN) x
CAREL slave devices (485) x x x x x
pCOexp 485 x x x x x
pCOexp tLAN x
μChiller2 expansion x
Hydronic fan coil and CANbus x x
PlantVisorPRO local x x x x x
PlantWatchPRO x x x x x
PCGate x x x x x
WebGate x x x x x
GATEWAY**0 x x x x x
LON - Echelon FTT10 x
BACnet/MSTP (RS485) x
HTTP client x
BACnet/Ethernet x
BACnet/IP x
SNMP v1, SNMP v2C x
Modbus TCP/IP x
Modbus supervisor (RTU) x x x
Modbus slave devices x x x x x
pCOexp Modbus x x x - x x
Power + x x x - x x
Benshaw devices x x -
WinLoad local x x x x - x x
WinLoad remote, analogue modem x -
PlantVisorPRO remote, analogue
modem
x- x
WinLoad remote, GSM modem x -
PlantVisorPRO remote, GSM
modem
x- x
Send and receive SMS x - x
Belimo devices - x
Serial printer x - x
Pendrive x
Th-tune terminal x x
pGD Touch x

Carel pCO5+ Specifications

General

Series	pCO5+
Real-time Clock	Yes
Protection Rating	IP20
Processor	ARM Cortex-M3
Communication Ports	RS485
Display	LCD with backlight
Inputs	Digital and Analog
Outputs	Relay and Analog
Power Supply	24 VAC/DC
Humidity	10% to 90% non-condensing
Protocols	Modbus RTU, BACnet MS/TP
Input Voltage	24 VAC/VDC
Weight	300 g
Relay Outputs	Number varies depending on model
Analog Outputs	Number varies depending on model
