pCO5plus +0300020EN rel. 1.2 - 07.11.2013
4.12 pCO5+ terminals description
Please refer to the fi gures in the preceding pages regarding the pCO5+.
Ref. Term. Label Description
1
J1-1 G Supply voltage A(*)
J1-2 G0 Power supply reference
2
J24-1 +Vterm Power to additional terminal
J24-2 GND Power supply common
J24-3 +5 V
REF Power to 0 to 5 V ratiometric probes
3
J2-1 U1 Universal input/output 1
J2-2 U2 Universal input/output 2
J2-3 U3 Universal input/output 3
J2-4 GND Common for universal inputs/outputs 1, 2, 3
3
J3-1 U4 Universal input/output 4
J3-2 GND Common for universal input/output 4
J3-3 U5 Universal input/output 5
J3-4 GND Common for universal input/output 5
3
J6-1 U6 Universal input/output 6
J6-2 U7 Universal input/output 7
J6-3 U8 Universal input/output 8
J6-4 GND Common for universal inputs/outputs 6, 7, 8
3
J20-3 U9 Universal input/output 9
J20-4 GND Common for universal input/output 9
J20-5 U10 Universal input/output 10
J20-6 GND Common for universal input/output 10
4 J2-5 +VDC Power to active probes
5 Button for setting pLAN address, secondary display, indicator LEDs
6
J4-1 VG Voltage A(*) to optically-isolated analogue output
J4-2 VG0
Power to optically-isolated analogue output, at 0
Vac/Vdc
7
J4-3 Y1 Analogue output 1, at 0 to 10 V
J4-4 Y2 Analogue output 2,at 0 to 10 V
J4-5 Y3 Analogue output 3, at 0 to 10 V
J4-6 Y4 Analogue output 4, at 0 to 10 V
7
J20-1 Y5 Analogue output 5, at 0 to 10 V
J20-2 Y6 Analogue output 6, at 0 to 10 V
8
J5-1 ID1 Digital input 1, at voltage A(*)
J5-2 ID2 Digital input 2, at voltage A(*)
J5-3 ID3 Digital input 3, at voltage A(*)
J5-4 ID4 Digital input 4, at voltage A(*)
J5-5 ID5 Digital input 5, at voltage A(*)
J5-6 ID6 Digital input 6, at voltage A(*)
J5-7 ID7 Digital input 7, at voltage A(*)
J5-8 ID8 Digital input 8, at voltage A(*)
J5-9 IDC1
Common for digital inputs 1 to 8 (negative pole for
DC power supply)
8
J7-1 ID9 Digital input 9, at voltage A(*)
J7-2 ID10 Digital input 10, at voltage A(*)
J7-3 ID11 Digital input 11, at voltage A(*)
J7-4 ID12 Digital input 12, at voltage A(*)
J7-5 IDC9
Common for digital inputs 9 to 12 (negative pole
for DC power supply)
8
J20-7 ID17 Digital input 17, at voltage A(*)
J20-8 ID18 Digital input 18, at voltage A(*)
J20-9 IDC17
Common for digital inputs 17 and 18 (negative
pole for DC power supply)
9
J8-1 ID13H Digital input 13, at voltage B(**)
J8-2 ID13 Digital input 13, at voltage A(*)
J8-3 IDC13
Common for digital inputs 13 and 14 (negative
pole for DC power supply)
J8-4 ID14 Digital input 14, at voltage A(*)
J8-5 ID14H Digital input 14, at voltage B(**)
9
J19-1 ID15H Digital input 15, at voltage B(**)
J19-2 ID15 Digital input 15, at voltage A(*)
J19-3 IDC15
Common for digital inputs 15 and 16 (negative
pole for DC power supply)
J19-4 ID16 Digital input 16, at voltage A(*)
J19-5 ID16H Digital input 16, at voltage B(**)
10 J10 - pLAN telephone cable connector
11
J11-1 Tx-/Rx- Tx-/Rx- pLAN RS485 port
J11-2 Tx+/Rx+ Tx+/Rx+ pLAN RS485 port
J11-3 GND GND pLAN RS485 port
12 - - Reserved
13 - - Reserved
14 - - Reserved
Ref. Term. Label Description
15
J12-1 C1 Common for relays 1, 2, 3
J12-2 NO1 Normally open contact, relay 1
J12-3 NO2 Normally open contact, relay 2
J12-4 NO3 Normally open contact, relay 3
J12-5 C1 Common for relays 1, 2, 3
15
J13-1 C4 Common for relays 4, 5, 6
J13-2 NO4 Normally open contact, relay 4
J13-3 NO5 Normally open contact, relay 5
J13-4 NO6 Normally open contact, relay 6
J13-5 C4 Common for relays 4, 5, 6
15
J14-1 C7 Common for relay 7
J14-2 NO4 Normally open contact, relay 7
J14-3 C7 Common for relay 7
15
J15-1 NO8 Normally open contact, relay 8
J15-2 C8 Common for relay 8
J15-3 CO8 Normally closed contact, relay 8
15
J16-1 C9 Common for relays 9, 10, 11
J16-2 NO9 Normally open contact, relay 9
J16-3 NO10 Normally open contact, relay 10
J16-4 NO11 Normally open contact, relay 11
J16-5 C9 Common for relays 9, 10, 11
15
J17-1 NO12 Normally open contact, relay 12
J17-2 C12 Common for relay 12
J17-3 NC12 Normally closed contact, relay 12
15
J18-1 NO13 Normally open contact, relay 13
J18-2 C13 Common for relay 13
J18-3 NC13 Normally closed contact, relay 13
15
J21-1 NO14 Normally open contact, relay 14
J21-2 C14 Common for relay 14
J21-3 NC14 Normally closed contact, relay 14
J21-4 NO15 Normally open contact, relay 15
J21-5 C15 Common for relay 15
J21-6 NC15 Normally closed contact, relay 15
J22-1 C16 Common for relays 16, 17, 18
J22-2 NO16 Normally open contact, relay 16
J22-3 NO17 Normally open contact, relay 17
J22-4 NO18 Normally closed contact, relay 18
J22-5 C16 Common for relays 16, 17, 18
15
J21-1 C14 Common for relays 14, 15, 16
J21-2 NO14 Normally open contact, relay 14
J21-3 NO15 Normally open contact, relay 15
J21-4 NO16 Normally open contact, relay 16
J21-5 C14 Common for relays 14, 15, 16
J22-1 C17 Common for relays 17, 18, 19, 20
J22-2 NO17 Normally open contact, relay 17
J22-3 NO18 Normally open contact, relay 18
J22-4 NO19 Normally open contact, relay 19
J22-5 NO20 Normally open contact, relay 20
J22-6 C17 Common for relays 17, 18, 19, 20
15
J19-1 C21 Common for relays 21, 22, 23, 24
J19-2 NO21 Normally open contact, relay 21
J19-3 NO22 Normally open contact, relay 22
J19-4 NO23 Normally open contact, relay 23
J19-5 NO24 Normally open contact, relay 24
J19-6 C21 Common for relays 21, 22, 23, 24
15
J20-1 C25 Common for relays 25, 26, 27, 28, 29
J20-2 NO25 Normally open contact, relay 25
J20-3 NO26 Normally open contact, relay 26
J20-4 NO27 Normally open contact, relay 27
J20-5 NO28 Normally open contact, relay 28
J20-6 NO29 Normally open contact, relay 29
J20-7 C25 Common for relays 25, 26, 27, 28, 29
16
J25-1 Tx-/Rx- Tx-/Rx- BMS2 RS485 port
J25-2 Tx+/Rx+ Tx+/Rx+ BMS2 RS485 port
J25-3 GND GND BMS2 RS485 port
17
J26-1 Tx-/Rx- Tx-/Rx- Fieldbus 2 RS485 port
J26-2 Tx+/Rx+ Tx+/Rx+ Fieldbus 2 RS485 port
J26-3 GND GND Fieldbus 2 RS485 port
18 Port J26 confi guration microswitches
19
J23-1 Tx-/Rx- Tx-/Rx- Fieldbus 2 RS485 port
J23-2 Tx+/Rx+ Tx+/Rx+ Fieldbus 2 RS485 port
J23-3 GND GND Fieldbus 2 network RS485 port
