Carel SmartCella User Manual

43
ENG
“SmartCella manual” +0300084EN - rel. 1.2 - 28.03.2017
Three-phase version
Speci cations WP00B14A10 WP00B24A10 WP00B34A10 WP00B44A10 WP00B47B20 WP00B57B20
Power supply 400V 3~ +N+E 50/60Hz
Max compressor power 5.5HP 7.5HP
Protectors Power Disconnect
switch
40A
Evaporator, condenser and
defrost protection
Circuit
breaker
10A 16A
Compressor protection Adjustable
motor
protector
1.6-2.5A 2.5-4A 4-6.3A 6.3-10A 10-16A
Auxiliary circuit protection Circuit
breaker
6A
Inputs Room temperature probe ST1 NTC
Defrost probe ST2 NTC
Door switch (or additional
probe)
MS1 voltage-free contact, contact resistance < 10 Ω, closing current 6 mA
S3 (probe 3)
NTC
Confi gurable digital input
(or additional probe) *
DI3 voltage-free contact, contact resistance < 10 Ω, closing current 6 mA
NTC
Safety thermostat yes
Thermal overload evaporator fan yes
Evaporator / condenser / defrost
protection alarm
yes
Compressor / high pressure switch /
compressor Kriwan protection alarm
yes
Outputs Evaporator fan 230V 1~+N+E 500W 2.5A AC3 400V 3~+N+E 2kW 3.3A AC3
Condenser fan 230V 1~+N+E 800W 3.9A AC3 230V 1~+N+E 800W 3.9A AC3
Defrost 400V 3~+T 6kW 9A AC1 400V 3~+T 9kW 13A AC1
Light (or AUX, confi gurable) 230V 1~+N+E 800W 3.9A AC3 230V 1~+N+E 800W 3.9A AC3
Solenoid valve yes
Compressor oil heater yes
Tab. 9.b
* To be connected directly to terminals 11 and 12 on the electronic board.
Casing plastic, dimensions 491x380x168
Materials polycarbonate cover, technopolymer shell
Display digits, 3 digit LED
display, from -99 to 999
operating status indicated by graphic icons on display
status of loads signalled by LEDs on the panel
Keypad 4-button membrane keypad
Buzzer available on all models
Serial interface external. Available on all models on request
Repeater display interface external. Available on all models on request
Maximum distance between interface and display 10 m
Programming key Available on all models on request
Op. temp. -10T50 °C
Op. humidity <90% RH non-condensing
Storage temp. -20T70 °C
Storage humidity <90% RH non-condensing
Front panel ingress protection IP56
Cleaning front panel of the device only use neutral detergents and water
Safety standards compliant with relevant European standards
Tab. 9.c
