7. PARAMETER TABLE
Symbol Code Parameter
Models U-M. Type Min. Max. Def.
Pw Password WE00S%, WE00C% e WP% - C 0 200 22
/2 Measurement stability WE00S%, WE00C% e WP% - C 1 15 4
/3 Probe display stability WE00S%, WE00C% e WP% - C 0 15 0
/4 Virtual probe composition WE00S%, WE00C% e WP% - C 0 100 0
/5 Temperature unit of measure (0: °C ,1: °F) WE00S%, WE00C% e WP% fl ag C 0 1 0
/6 Display decimal point
with tenths of a degree
without tenths of a degree
WE00S%, WE00C% e WP% fl ag C 0 1 0
/tI Display on user terminal
1: virtual probe
2: probe 1
3: probe 2
4: probe 3
5: probe 4
6: reserved
7: set point
WE00S%, WE00C% e WP% - C 1 7 1
/tE Reading on remote display
0: remote terminal not present
1: virtual probe
2: probe 1
3: probe 2
4: probe 3
5: probe 4
6: reserved
WE00S%, WE00C% e WP% - C 0 6 0
/P Type of probe
0: NTC standard with range -50T90°C
1: NTC enhanced with range -40T150°C
2: PTC standard with range -50T150°C
WE00S%, WE00C% e WP% - C 0 2 0
/A2 Confi guration of probe 2 (S2)
0: absent
1: product (display only)
2: defrost
3: condenser
4: antifreeze
WE00S%
WE00C% e WP%
-
-
C
C
0
0
4
4
0
2
/A3 Confi guration of probe 3 (S3/DI1) As for /A2 WE00S%, WE00C% e WP% - C 0 4 0
/A4 Confi guration of probe 4 (S4/DI2) As for /A2 WE00S%, WE00C% e WP% - C 0 4 0
/A5
Confi guration of p
robe 5 (S5/ID3) As for /A2
WE00S%, WE00C% e WP% - C 0 4 0
/c1 Calibration of probe 1 WE00S%, WE00C% e WP% °C/°F C -20 20 0.0
/c2 Calibration of probe 2 WE00S%, WE00C% e WP% °C/°F C -20 20 0.0
/c3 Calibration of probe 3 WE00S%, WE00C% e WP% °C/°F C -20 20 0.0
/c4 Calibration of probe 4 WE00S%, WE00C% e WP% °C/°F C -20 20 0.0
/c5
Calibration of probe 5
WE00S%, WE00C% e WP% °C/°F C -20 20 0.0
St Set Point WE00S%, WE00C% e WP% °C/°F F r1 r2 0.0
rd Diff erential WE00S%, WE00C% e WP% °C/°F F 0.1 20 2.0
rn Dead band WE00S%, WE00C% e WP% °C/°F C 0.0 60 4.0
rr Reverse diff erential WE00S%, WE00C% e WP% °C/°F C 0.1 20 2.0
r1 Minimum set point WE00S%, WE00C% e WP% °C/°F C -50 r2 -50
r2 Maximum set point WE00S%, WE00C% e WP% °C/°F C r1 200 60
r3 Operating mode
0: Direct with defrost control (cooling)
1: Direct (cooling)
2: Reverse-cycle (heating)
WE00S%, WE00C% e WP% fl ag C 0 2 0
r4 Automatic night-time set point variation WE00S%, WE00C% e WP% °C/°F C -20 20 3.0
r5 Enable temperature monitoring
0: disabled, 1: enabled
WE00S%, WE00C% e WP% fl ag C 0 1 0
rt Duration of current max and min temperature monitoring session WE00S%, WE00C% e WP% ore F 0 999 -
rH Maximum temperature read WE00S%, WE00C% e WP% °C/°F F - - -
rL Minimum temperature read WE00S%, WE00C% e WP% °C/°F F - - -
c0 Compressor, fan and AUX start delay at power on WE00S%, WE00C% e WP% min C 0 15 0
c1 Minimum time between successive compressor starts WE00S%, WE00C% e WP% min C 0 15 0
c2 Minimum compressor OFF time WE00S%, WE00C% e WP% min C 0 15 0
c3 Minimum compressor ON time WE00S%, WE00C% e WP% min C 0 15 0
c4 Compressor running time with duty setting WE00S%, WE00C% e WP% min C 0 100 0
cc Continuous cycle duration WE00S%, WE00C% e WP% ore C 0 15 0
c6 Low temperature alarm bypass after continuous cycle WE00S%, WE00C% e WP% ore C 0 250 2
c7 Maximum pump down time (PD)
0: pump down disabled
WE00S%, WE00C% e WP% s C 0 900 0
c9 Enable autostart function in PD
0: disabled
1: pump down whenever closing pump down & following low
pressure switch activation with no cooling demand
WE00S%, WE00C% e WP% fl ag C 0 1 0
c10 Pump down by time or pressure
0: Pump down by pressure
1: Pump down by time
WE00S%, WE00C% e WP% fl ag C 0 1 0
c11 Second compressor start delay WE00S%, WE00C% e WP% s C 0 250 4
