Symbol Code Parameter
Models U-M. Type Min. Max. Def.
d0 Typo of defrost
0: Electric heater by temperature
1: Hot gas by temperature
2: Electric heater by time (Ed1, Ed2 not shown)
3: Hot gas by time (Ed1, Ed2 not shown)
4: Electric heater by time with temperature control (Ed1, Ed2 not
shown)
WE00S%, WE00C% e WP% ag C 0 4 0
dI MAximum time between consecutive defrosts
0: defrost not performed
WE00S%, WE00C% e WP% ore F 0 250 8
dt1 End defrost temperature probe 2 WE00S%, WE00C% e WP% °C/°F F -50 200 4.0
dt2 End defrost temperature probe 3 WE00S%, WE00C% e WP% °C/°F F -50 200 4.0
dP1 Maximum defrost duration WE00S%, WE00C% e WP% min F 1 250 30
dP2 Maximum defrost duration, aux evaporator WE00S%, WE00C% e WP% min F 1 250 30
d3 Defrost activation delay WE00S%, WE00C% e WP% min C 0 250 0
d4 Defrost at start-up
0: disabled
1: enabled
WE00S%, WE00C% e WP% ag C 0 1 0
d5 Defrost delay on start-up (if d4=1) or from DI WE00S%, WE00C% e WP% min C 0 250 0
d6 Terminal display during defrost
0: Alternating display of temperature and dEF value
1: display disabled
2: dEF
WE00S%, WE00C% e WP% - C 0 2 1
dd Dripping time after defrost (fans off ) WE00S%, WE00C% e WP% min F 0 15 2
d8 High temperature alarm bypass time after defrost (and door
open)
WE00S%, WE00C% e WP% ore F 0 250 1
d8d Alarm bypass time after door open WE00S%, WE00C% e WP% min C 0 250 0
d9 Defrost priority over compressor protectors
0: The protection times c1, c2 and c3 are observed
1: The protection times c1, c2 and c3 are not observed
WE00S%, WE00C% e WP% ag C 0 1 0
d/1 Display of defrost probe 1 WE00S%, WE00C% e WP% °C/°F F - - -
d/2 Display of defrost probe 2 WE00S%, WE00C% e WP% °C/°F F - - -
dC Time base for defrost
0: dI in hours, dP1 and dP2 in minutes
1: dI in minutes, dP1 and dP2 in seconds
WE00S%, WE00C% e WP% ag C 0 1 0
d10 Defrost time in running time mode
0= function disabled
WE00S%, WE00C% e WP% ore C 0 250 0
d11 Running time defrost temperature threshold WE00S%, WE00C% e WP% °C/°F C -20 20 1.0
d12 Advanced defrost WE00S%, WE00C% e WP% - C 0 3 0
dn Nominal defrost duration WE00S%, WE00C% e WP% - C 1 100 65
dH Proportional factor for variation of dI WE00S%, WE00C% e WP% - C 0 100 50
A0 Alarm and fan diff erential WE00S%, WE00C% e WP% °C/°F C 0.1 20 2.0
A1 Alarm threshold (‘AL and AH’) relative to set point or absolute
0: AL and AH are relative thresholds to the set point
1: AL and AH are absolute thresholds
WE00S%, WE00C% e WP% ag C 0 1 0
AL Low temperature alarm threshold WE00S%, WE00C% e WP% °C/°F F -50 200 0.0
AH High temperature alarm threshold WE00S%, WE00C% e WP% °C/°F F -50 200 0.0
Ad Low and high temperature alarm delay WE00S%, WE00C% e WP% min F 0 250 120
A4 Digital input 1 confi guration (DI1)
0: Input not active
1: Immediate external alarm
2: Delayed external alarm
3: If model M, probe selection
3: Other models enable defrost
4: Start defrost
5: Door switch with compressor and fan stop
6: Remote on/off
7: Curtain switch
8: Low pressure switch
9: Door switch with fan stop
10: Direct/reverse operation
11: Light sensor
12: Activation of AUX output
13: Door switch with compressor and fans off and light not
managed
14: Door switch with fans off and light not managed
WE00S% e WE00C%
WP%
-
-
C
C
0
0
14
14
0
5
A5 Digital input 2 confi guration (DI2) / As for A4 WE00S% e WE00C%
WP%
-
-
C
C
0
0
14
14
0
1
A6 Stop compressor from external alarm WE00S%, WE00C% e WP% min C 0 100 0
A7 Digital alarm input delay WE00S%, WE00C% e WP% min C 0 250 0
A8 Enable alarms ‘Ed1’ and ‘Ed2’ (end defrost by timeout)
0: Alarm signals Ed1 and Ed2 enabled
1: Alarm signals Ed1 and Ed2 disabled
WE00S%, WE00C% e WP% ag C 0 1 0
A9
Confi guration of digital input 3
(ID3) As for /A2
WE00S%, WE00C% e WP% - C 0 14 0
Ac High condenser temperature alarm threshold WE00S%, WE00C% e WP% °C/°F C 0.0 200 70
AE High condenser temperature alarm diff erential WE00S%, WE00C% e WP% °C/°F C 0.1 20 10
Acd High condenser temperature alarm delay WE00S%, WE00C% e WP% min C 0 250 0
AF Light sensor OFF time WE00S%, WE00C% e WP% s C 0 250 0
ALF Antifreeze alarm threshold WE00S%, WE00C% e WP% °C/°F C -50 200 -5
AdF Antifreeze alarm delay WE00S%, WE00C% e WP% min C 0 15 1
