Symbol Code Parameter
Models U-M. Type Min. Max. Def.
F0 Evaporator fan management
0: always on
1: Activation based on Sd-Sv ( diff erence between virtual probe
and evaporator temperature)
2: Activation based on Sd (evaporator temperature)
WE00C% e WP% fl ag C 0 2 0
F1 Fan activation temperature (only if F0= 1 or 2) WE00C% e WP% °C/°F F -50 200 5
F2 Evaporator fans with compressor OFF
0: see F0
1: always off
WE00C% e WP% fl ag C 0 1 1
F3 Evaporator fans during defrost
0: Fans operate
1: Fans do not operate
WE00C% e WP% fl ag C 0 1 1
Fd Post dripping time (fans OFF) WE00C% e WP% min F 0 15 1
F4 Condenser fan stop temperature WE00C% e WP% °C/°F C -50 200 40
F5 Condenser fan start diff erential WE00C% e WP% °C/°F C 0.1 20 5
H0 Serial address WE00S%, WE00C% e WP% - C 0 207 1
H1 AUX1 output confi guration
0: normally energised alarm
1: normally de-energised alarm
2: Auxiliary
3: Light
4: Auxiliary evaporator defrost
5: Pump down valve
6: Condenser fan
7: Delayed compressor
8: Auxiliary with deactivation when OFF
9: Light with deactivation when OFF
10: No function
11: Reverse with neutral zone
12: Second compressor step
13: Second compressor step with rotation
WE00C%
WP%
fl a g
fl a g
C
C
0
0
13
13
1
3
H2 Disable keypad/ir
Parameter “H2” LIGHT ON/OFF AUX HACCP PRG/MUTE (mute) UP/CC DOWN/DEF SET parameter F modi cation Set point modi cation
0••
1
2••
3
4• •••
5 • •• ••
6••••
Keypad function
"•" = Disabled
WE00S%, WE00C% e WP% fl ag C 0 6 1
H3
not user
- C 0 255 0
H4 Buzzer
0: enabled
1: disabled
WE00S%, WE00C% e WP% fl ag C 0 1 0
H6 Terminal keypad lock confi guration WE00S%, WE00C% e WP% - C 0 255 0
H8 Output switched with scheduler
0: light
1: Aux
WE00S%, WE00C% e WP% fl ag C 0 1 0
H9 Set point variation with time band
0: Set point variation with time band disabled
1: Set point variation with time band enabled
WE00S%, WE00C% e WP% fl ag C 0 1 0
Hdh Anti-sweat heater off set WE00S%, WE00C% e WP% °C/°F C -50 200 0
HAn Number of HA alarms WE00C2HC% - C 0 15 0
HA...HA2
y__
M__
d__
h__
n__
t__
HA HACCP alarms activated (press Set)
Year
Month
Day
Hour
Minute
Duration
WE00C2HC% -
years
months
days
hours
min.
hours
C
0
1
1
0
0
0
-
99
12
7
23
59
99
-
0
0
0
0
0
0
HFn Number of HF alarms WE00C2HC% - C 0 15 0
HF...HF2
y__
M__
d__
h__
n__
t__
Date/time of last HF event
Year
Month
Day
Hour
Minute
Duration
WE00C2HC% -
years
months
days
hours
min.
hours
C
0
1
1
0
0
0
-
99
12
7
23
59
99
-
0
0
0
0
0
0
Htd HACCP alarm delay WE00C2HC% min C 0 250 0
