Carel SmartCella User Manual

36
ENG
“SmartCella manual” +0300084EN - rel. 1.2 - 28.03.2017
Symbol Code Parameter
Models U-M. Type Min. Max. Def.
td1...8
d__
h__
n__
Defrost 1...8 (press Set)
Day
Hour
Minute
WE00C2HC% -
days
hours
min.
C-
0
0
0
-
11
23
59
-
0
0
0
ton
d__
h__
n__
Light/aux on time
Day
Hour
Minute
WE00C2HC% -
days
hours
min.
C-
0
0
0
-
11
23
59
-
0
0
0
toF
d__
h__
n__
Light/aux off time
Day
Hour
Minute
WE00C2HC% -
days
hours
min.
C-
0
0
0
-
11
23
59
-
0
0
0
tc
y__
M__
d__
u__
h__
n__
RTC date/time
Year
Month
Days of month
Days of week
Hours
Minute
WE00C2HC% -
years
months
days
days
hours
min.
-
0
1
1
1
0
0
-
99
12
31
7
23
59
-
0
1
1
6
0
0
Tab. 7.a
7.14 Variables only accessible via serial
connection
Description Type CAREL SVP Modbus R/W
Virtual probe A33R
Probe 1 reading A44R
Probe 2 reading A55R
Probe 3 reading A66R
Probe 4 reading A77R
Number of parameter sets available I 137 237 R
Digital input 1 status D 6 6 R
Digital input 2 status D 7 7 R
Virtual probe fault alarm D 9 9 R
Probe alarm 1 D1010R
Probe alarm 2 D1111R
Probe alarm 3 D1212R
Probe alarm 4 D1313R
Compressor status relay D 1 1 R
Defrost relay status D 2 2 R
Fan relay status D33R
AUX relay status D44R
Digital input 1 status D 6 6 R
Digital input 2 status D 7 7 R
Defrost status D3131R
Defrost call command D 34 34 RW
Continuous cycle status D 35 35 R
Continuous cycle call command D 36 36 RW
Door status D3737R
AUX activation command D 57 57 RW
Light activation command D 58 58 RW
Controller ON/OFF D 59 59 RW
Password I 14 114 RW
Virtual probe fault alarm D 9 9 R
Probe 1/2/3/4/5 fault alarm D 10/11/12/13/14 10/11/12/13/14 R
Low temperature alarm D 15 15 R
High temperature alarm D 16 16 R
Immediate external alarm D 17 17 R
Delayed external alarm D 18 18 R
Evaporator 1 defrost timeout alarm D 19 19 R
Evaporator 2 defrost timeout alarm D 20 20 R
Pump down timeout alarm D 21 21 R
Low pressure alarm D 21 21 R
High condenser temperature alarm D 24 24 R
Door open for too long alarm D 25 25 R
RTC error D2626R
Control parameter EEPROM error D 27 27 R
Operating parameter EEPROM error D 28 28 R
HA HACCP alarm D 29 29 R
HF HACCP alarm D 30 30 R
Alarm autostart in pump down D 32 32 R
Tab. 7.b
