Maintenance and Troubleshooting
3–22 AA2204_en | 2012-07-27
Roller Knobs
For some jams, you can remove the film by turning a knob to move the film out of the
imager. See details in the film jam instructions.
Figure 6: Knobs for manual film removal
Knobs Description
1 Exit Roller
2 Exposure Transport
H241_000
2
1
