Maintenance and Troubleshooting
AA2204_en | 2012-07-27 3–25
Clear Film Jam Code 326 / Jam in Area 2 or 3
This error displays as code 26326 at the Web Portal.
1. If the Pause symbol is on, press it and wait until it goes off.
2. Remove the left cover:
a. Open the film supply.
b. Remove the top cover.
c. Turn the knurled knobs by hand.
3. Rotate the exit roller knob clockwise until a film exits the imager.
4. If a film does not exit:
a. Reach into Area 2 and remove any film.
b. If the film is not loose, carefully turn the exposure transport knob clockwise to
remove the film from the rollers.
5. Reinstall the covers.
Related topics
Film Jam Indication and Areas
H210_1017AC
H210_1017ACA
2 Screws
