Carrier 48FC Series User Manual

132
CONTROL SET POINT AND CONFIGURATION LOG
MODEL NO.:
SERIAL NO.:
DATE:
TECHNICIAN:
SOFTWARE VERSION :
MBB: CESR131651--
INDICATE UNIT SETTINGS BELOW
CONTROL TYPE: Thermostat/T55 Space Temp./T--56 Space Temp./T--59 Space Temp.
SET POINT Cooling Occupied: Unoccupied:
Heating Occupied: Unoccupied:
Settings -- Main Menu Layout
DISPLAY TEXT EXP ANDED DISPLAY TEXT VALUES UNITS DEFAUL T POINT ENTRY
SETTINGS Settings Menu
SPACE SET POINTS Space Setpoints Adjustment Menu
OCC COOL SETPOINT Occupied Cool Setpoint 55 to 80 °F 78 OCSP
OCC HEAT SETPOINT Occupied Heat Setpoint 55 to 80 °F 68 OHSP
UNOCC COOL SETPNT Unoccupied Cool Setpoint 65 to 95 °F 85 UCSP
UNOCC HEAT SETPNT Unoccupied Heat Setpoint 40 to 80 °F 60 UHSP
H E A T --- C O O L S P G A P Heat--- Cool Setpoint Gap 2to10 °F 5 HCSP_GAP
SPT SLIDER RANGE SPT Offset Range (+/--- ) 0to5 °F 5 SPTO_RNG
OCC SPRH SETPOINT Occupied SPRH Setpoint 0 to 100 % 50 SPRH_OSP
UNOCC SPRH SET PT Unoccupied SPRH Setpoint 0 to 100 % 80 SPRH_USP
SPRH RH DEADBAND Space R H Deadband 2to20 % 8 SPRH_DB
SA TEMPERING SP SA tempering Set point 30 to 80 °F 55 SATEMPSP
TEMP DEMAND CONFIG Temperature Demand Configuration
menu
L OW COOL DMD ON Low Cool Demand On --- 1 t o 2 °F 0.5 DMDLCON
HIGH COOL DMD ON High Cool Demand On 0.5 to 20 °F 1.5 DMDHCON
L OW COOL DMD OFF Low Cool Demand Off --- 1 t o 2 °F --- 0 . 5 DMDLCOFF
COOL DMD LEVEL UP Cool Demand Level Up --- 2 t o 2 °F --- 0 . 2 CDMD_LUP
LOW HEAT DMD ON Low Heat Demand On --- 1 t o 2 °F 0.5 DMDLHON
HIGH HEAT DMD ON High Heat Demand On 0.5 to 20 °F 2 DMDHHON
LOW HEAT DMD OFF Low Heat Demand Off --- 1 t o 2 °F --- 0 . 5 DMDLHOFF
HEAT DMD LEVEL UP Heat Demand Level Up --- 2 t o 2 °F --- 0 . 2 HDMD_LUP
DEMAND TIMEGUARD1 Space Demand Time Guard1 60 to 600 sec 120 TDMD_TG1
DEMAND TIMEGUARD2 Space Demand Time Guard2 0 to 600 sec 240 TDMD_TG2
DEMAND TIMEGUARD3 Space Demand Time Guard3 5 to 120 min 10 TDMD_TG3
DMD LIMIT CONFIG DEMAND LIMIT CONFIG
COOL DMD LIM LEV1 COOL DMD Offset level 1 0to99 °F 1 CLDOLEV1
COOL DMD LIM LEV2 COOL DMD Offset level 2 0to99 °F 3 CLDOLEV2
COOL DMD LIM LEV3 COOL DMD Offset level 3 0to99 °F 5 CLDOLEV3
HEAT DMD LIM LEV1 Heat DMD Offset level 1 0to99 °F 1 HTDOLEV1
HEAT DMD LIM LEV2 Heat DMD Offset level 2 0to99 °F 3 HTDOLEV2
HEAT DMD LIM LEV3 Heat DMD Offset level 3 0to99 °F 5 HTDOLEV3
CLOCK Clock Adjustment Menu
TIME Clock Hour and Minute xx:xx hh.mm TIME
DATE Current Date MM/DD/YYYY DATE
DAYLIGHT SAVINGS Daylight Savings Configuration Menu
DAYLIGHT SAVINGS? DST allowed? Enable/Disable 1 DST_CFG
DST START MONTH DST Start Month 1=JANUARY,
2=FEBRUARY,
3=MARCH,
4=APRIL,
5=MAY,
6=JUNE,
7=JULY,
8=AUGUST,
9=SEPTEMBER,
10=OCTOBER,
11=NOVEMBER,
12=DECEMBER
3 STARTM
DST START WEEK DST Start Week 1to5 2 STARTW
DST START DAY DST Start Day 1=MONDAY,
2=TUESDAY,
3=WEDNESDAY,
4=THURSDAY,
5=FRIDAY,
6=SATURDAY,
7=SUNDAY
7 STARTD
DST MINS TO ADD DST Minutes to Add 0to90 min 60 MINADD
