Carrier 48FC Series User Manual

61
APPENDIX A: SystemVut Controller Display
Run Status Main Menu Layout
DISPLAY TEXT EXPANDED DISPLAY TEXT VALUES UNITS WRITE STATUS POINT
SHUTDOWN UNIT? Local Unit Shutdown Req. Yes/No Command LOCSHUT
RUN STATUS Run Status Menu
MODE Mode Status Menu
MODE Operating Mode see Appendix B MODETEXT
S U B --- M O D E O p e r a t i n g S u b --- M o d e see Appendix B SUBMTEXT
DEMAND System Demand see Appendix B SYS_DMDT
LINKAGE ACTIVE Linkage Active Yes/No LNK_ACT
EFF COOL SETPOINT Cool Setpoint In Effect xx.x °F CSP_EFF
EFF HEAT SETPOINT Heat Setpoint In Effect xx.x °F HSP_EFF
DEMAND CTRL TEMP Effective Demand Temp xxx.x °F TEMP_EFF
OCC SPRH SETPOINT Occupied SPRH Setpoint xxx.x % SPRH_OSP
UNOCC SPRH SP Unoccupied SPRH Setpoint xxx.x % SPRH_USP
COOL MODE T.GUARD Cool Mode Select T.guard xxx sec COOLMSTG
HEAT MODE T.GUARD Heat Mode Select T.guard xxx sec HEATMSTG
COOLING DEMAND Space Cooling Demand xx.x ΔF COOL_DMD
COOL DEMAND TREND Cooling Demand Trend xx.x CLDTREND
HEATING DEMAND Heating Space Demand xx.x ΔF HEAT_DMD
HEAT DEMAND TREND Heat Space Demand Trend xx.x HTDTREND
DMD LIMIT STATUS DEMAND LIMIT STATUS
COOL DMD LIM OFF Cool Demand Limiting Yes/No CDMLMOFF
HEAT DMD LIM OFF Heat Demand Limiting Yes/No HDMLMOFF
COOL DMD LIM LEV Cool demand Limit Level 0to3 CDMDLLEV
HEAT DMD LIM LEV Heat demand Limit Level 0to3 HDMELLEV
CL DMD LIM OFFSET Cool Demand limit offset xx.x °F COOLDLMO
HT DMD LIM OFFSET Heat Demand limit offset xx.x °F HEATDLMO
COOL Cooling Status Menu
COMMANDED IDF RPM IDF Commanded RPM 0 to 3000 RPM FSPD_RPM
ACTIVE COOL STAGE Actual Cool Stage Active x ACTCSTGS
ECON CMD POSITION Econo Commanded Position 0 to 100 % Forcible DAMPCMD
REQ. DEHUM LEVEL Requested Dehum Level 0=Normal,
1 = Subcool,
2=Reheat,
REQDHLEV
MECHANICAL COOLING Mechanical Cooling Detail Sub--- Menu
OK TO MECH COOL Ok to use compressors? Yes/No OKMECHCL
MECH COOL ACTIVE Mechanical Cool active? Ye s/No MECHCOOL
MAX COOL STAGES Max Allowed Cool Stages 0to3 Forcible MAXCSTGS
REQ. COOL STAGES Requested Cooling Stages 0to3 REQCSTGS
ACTIVE COOL STAGE Actual Cool Stage Active x ACTCSTGS
ODF STATE ODF State 0=OFF,
1=ON,
2=LOW,
3=HIGH
ODFSTATE
COMP A1 TIMEGUARD Compressor A1 Timeguard xxx sec TIMGD_A1
CMP LDR TIMEGUARD Comp A1 Loader Timeguard xxx sec TIMG_ALD
SUPPLY AIR TREND Supply Air Temp Trend xxx.x SATTREND
COMP A1 STRIKES Compressor A1 strikes x A1STRIKE
HI PRESS OVERRIDE High Pressure Override Yes/No HP_OVR
CIRCUIT A LOCK OUT Circuit A Locked Out Yes/No CIRAL OCK
LOW COOL LOCKOUT Low cooling locked out Yes/No LC_L OCK
COMP A1 AVAILABLE Compressor A1 Available Yes/No CA1_AVAL
COMP A1 LOCKOUT Compressor A1 Locked Out Yes/No CA1_L OCK
FREE COOLING Free Cooling Detail Sub --- menu
OK TO FREE COOL OKtoUseFreeCooling? Yes/No OKFREECL
IN FREE COOLING Free Cooling active Yes/No FREECOOL
FREECOOL SAT SP Free Cooling SAT Setpnt xx.x °F FC_SATSP
REQ. DAMPER POS Requested Damper Pos 0 to 100 % REQDAMP
ECON OPERATIONAL? Econ Damper Operational Yes/No DAMPGOOD
DRY BULB LOCKOUT Dry Bulb Lockout Yes/No Forcible DBLOCK
ENTHALPY LOCKOUT Enthalpy Lockout Yes/No Forcible ENTHLOCK
OK TO UNOCC FC? Ok to Unocc Free Cool? Yes/No OKTOUFC
IN UNOC FREECOOL? Unocc Free Cool Active Yes/No UFC_ACT
UFC LOCKOUT? Unocc Free Cool Lockout Yes/No UNOCLOCK
