Carrier 48FC Series User Manual

119
APPENDIX E: BACnet* Points List
Analog Value (AV) Points
POINT DESCRIPTION POINT ACCESS UNITS
BACnet OBJECT
NAME
BACnet ID VALUE RANGE
CCN POINT
EQUIVALENT
2--- Pos Damper/ERV Channel R/W R/W erv2chan AV:8049 0TO2 EV2PCHAN
2Position/ERV ResetCount READ ONLY rs_erv2p AV:8046 0 TO 65535 RS_ERV2P
2Position/ERV Run Hours READ ONLY hrs hr_erv2p AV:8055 0 TO 999999 HR_ERV2P
2Position/ERV Starts READ ONLY st_erv2p AV:8047 0 TO 999999 ST_ERV2P
A1 Loader Resets Count READ ONLY rs_aldr AV:7012 0 TO 65535 RS_ALDR
Actual Cool Stage Active READ ONLY actcstgs AV:194 0TO3 ACTCSTGS
Actual Heat Stage Active READ ONLY acthstgs AV:46 0TO2 ACTHSTGS
Alarm display info READ ONLY alarm_info AV:14 0TO2 ALARM
Alarm Relay Resets Count READ ONLY rs_alm AV:99 0 TO 65535 RS_ALM
Alarm Relay Run Hours READ ONLY hrs hour_alarm AV :49 0 TO 999999 HR_ALM
Alarm Relay Starts READ ONLY st_alm AV:136 0 TO 999999 ST_ALM
Alarm Reset Counts READ ONLY st_alrst AV:137 0 TO 999999 ST_ALRST
Alarm Reset Resets Count READ ONLY rs_alrst AV:100 0 TO 65535 RS_ALRST
AQ Diff Low --- IAQ OVERRIDE R/W PPM aqd_low AV:443 0 TO 5000 AQD_L OW
AQ Differential High R/W daq_high AV:212 0 TO 5000 DAQ_HIGH
AQ Differential Low R/W R daq_low AV:213 0 TO 5000 DAQ_LOW
AQ DiffHigh--- IAQ OVERRIDE R/W PPM aqd_high AV:442 0 TO 5000 AQD_HIGH
Average Occup. Cool Stp. R/W °F lnk_ocsp AV:264 55 TO 80 LNK_OCSP
Average Occup. Heat Stp. R/W °F lnk_ohsp AV:266 55 TO 80 LNK_OHSP
Average Occup. Zone Temp R/W °F lnk_aozt AV:255 --- 40 TO 245 LNK_AOZT
Average Unocc. Cool Stp. R/W °F lnk_ucsp AV:274 65 TO 90 LNK_UCSP
Average Unocc. Heat Stp. R/W °F lnk_uhsp AV:275 40 TO 80 LNK_UHSP
AverageZoneTemperature R/W °F lnk_azt AV:256 --- 40 TO 245 LNK_AZT
BACKUP Preparation Time READ ONLY bkpreptm AV:336 0 TO 65535 BKPREPTM
BACnet device for IAQ R/W deviaq AV:8001 0 TO 4194303 DEVIAQ
BACnet device for OAQ R/W devoaq AV:8002 0 TO 4194303 DEVOAQ
BACnet device for OARH R/W devoarh AV:8004 0 TO 4194303 DEVOARH
BACnet device for OAT R/W devoat AV:8003 0 TO 4194303 DEVOAT
BACnet device for RARH R/W devrarh AV:8005 0 TO 4194303 DEVRARH
BACnet device for RAT R/W devrat AV:8006 0 TO 4194303 DEV RAT
BACnet device for SPRH R/W devsprh AV:8028 0 TO 4194303 DEVSPRH
BACnet device for SPT R/W devspt AV:8007 0 TO 4194303 DEVSPT
BACnet Device Macaddress R/W bac_mac AV:189 0 TO 127 BAC_MAC
BACnet ID Number R/W bac_id AV:188 0 TO 4194302 BAC_ID
Barometric Pressure R/W IN_HG_OF_KPAG barp AV:161 10 TO 35 BARP
Block No: in Master Zone R/W lnk_mzbk AV:262 0 TO 255 LNK_MZBK
CCH Max Temperature R/W °F cch_max_t AV:2 40 TO 90 CCHMAXT
CCH1 Relay Resets Count READ ONLY rs_cchr1 AV:294 0 TO 65535 RS_CCHR1
CCH1 Relay Run Hours READ ONLY hrs hour_cchr1 AV:242 0 TO 999999 HR_CCHR1
CCH1 Relay Starts READ ONLY st_cchr1 AV:301 0 TO 999999 ST_CCHR1
Change Filter Timer R/W hrs filter_service_hrs AV:2019 0 TO 9999 FILTLIFE
Change of value for IAQ R/W coviaq AV:8015 0TO60 COVIAQ
Change of value for OAQ R/W covoaq AV:8016 0TO60 COVOAQ
Change of value for OARH R/W covoarh AV:8018 0TO60 COVOARH
Change of value for OAT R/W covoat AV:8017 0TO60 COVOAT
Change of value for RARH R/W covrarh AV:8019 0TO60 COVRARH
Change of value for RAT R/W covrat AV:8020 0TO60 COVRAT
Change of value for SPRH R/W covsprh AV:8030 0TO60 COVSPRH
Change of value for SPT R/W covspt AV:8021 0TO60 COVSPT
Cir .A Discharge Pressure R/W PSI sdp_a AV:124 --- 67.06 TO 699.63 SDP_A
Cir.A Sat.Discharge Temp READ ONLY °F sdt_a AV:295 --- 100 TO 500 SDT_A
Cir.A Sat.Suction Temp READ ONLY °F sst_a AV:339 --- 100 TO 500 SST_A
Cir .A Suction Pressure READ ONLY PSI ssp_a AV:131 --- 47.33 TO 430.16 SSP_A
Circuit A Pressure Ratio READ ONLY cira_pr AV:204 14.5 TO 667.0 CIRA_PR
CLV_A Resets Count READ ONLY rs_clv_a AV:455 0 TO 65535 RS_CLV_A
CLV_A Run Hours READ ONLY hrs hr_clv_a AV:457 0 TO 999999 HR_CLV_A
CLV_A Starts READ ONLY st_clv_a AV:459 0 TO 999999 ST_CLV_A
CMP A1 Loader Run Hours READ ONLY hrs hr_aldr AV:7010 0 TO 999999 HR_ALDR
CMP A1 Loader Starts READ ONLY st_aldr AV:7011 0 TO 999999 ST_ALDR
cmp Loader Timeguard READ ONLY sec timg_ald AV:164 0 TO 600 TIMG_ALD
Comp A1 Resets Count READ ONLY rs_a1 AV:97 0 TO 65535 RS_A1
Compressor A1 Run Hours READ ONLY hrs hour_a1 AV:47 0 TO 999999 HR_A1
Compressor A1 Run Hours READ ONLY hrs hr_rlv_a AV:458 0 TO 999999 HR_RLV_A
* BACnet is a registered trademark of ASHRAE (American Society of Heating, Refrigerating and Air--- Conditioning Engineers).
