APPENDIX B: SystemVut Controller Text Point Reference
SystemVu Display Name = MODE
SystemVu Text point = MODETEX T
SystemVu Numeric point = SYSMODE
MODETEXT
SYS_MODE
OFF 1
COOL 2
HEAT 3
VENT 4
TEST 5
SystemVu Display Name = SUB ---MODE
SystemVu Text point = SUBMTEXT
SystemVu Numeric point = SUB_MODE
SUBMTEXT
SUB_MODE
ECON FREE COOLING 3
UNOCC. FREE COOL 4
MECH. COOLNG 5
ECON/MECH COOLING 6
DEHUM/MECH COOLING 7
DEHUMIDIFYING 8
DEHUM PREVENTED 9
COOLING PREVENTED 10
SHUTTING COOL OFF 11
HEATING 13
HEATING PREVENTED 14
SHUT TING HEAT OFF 15
OA TEMPERING 16
MODE TIMEGUARD 19, 26
SUPPLY FA N ON 20
MANUAL TEST 23
AUTO TEST 24
SHUTTING TEST OFF 25
IDLE --- NO DEMAND 27
UNIT DISABLED 28
URGENT SHUTDOWN 29
SAFETY CONTROL 30
STARTING UP 31
SystemVu Display Name = VENT MODE
SystemVu Text poin t = VENTT E XT
SystemVu Numeric point = VENTSTAT
VENTTEXT
VENTSTAT
SUPPLY FA N OFF 0
CIRCULATION 1
P R E --- OC C P U R G E 2
IAQ OVERRIDE 3
MINIMUM POSITION 4
UNDER VENTILATION 5
OVER VENTILATION 6
DCV POSITION 7
FREECOOL POSITION 8
TESTING 9
SystemVu Display Name = DEMAND
SystemVu Text poin t = SYS_DMDT
SystemVu Numeric point = SYS_DMD
SYSDMDT
SYS_DMD
NO DEMAND 0
DEHUM 4, 12
FAN ONL Y 8
LOW COOL 17, 25
MED COOL 18, 26
HIGH COOL 19, 27
LOW COOL DEHUM 21, 29
MED COOL DEHUM 22, 30
HIGH COOL DEHUM 23, 31
LOW HEAT 33, 37, 41, 45
HIGH HEAT 35, 39, 43, 47
SERVICE TEST 49
SHUTDOWN 65
SAFETY FAULT 66
EMERGENCY 67
UFC LOW COOL 81
UFC MED COOL 82
LOW UFC DEHUM 85
MED UFC DEHUM 86
HIGH UF C DEHUM 87
UFC HIGH COOL 83
SUP.AIRTEMPERING 129, 137
