Carrier 48FC Series User Manual

95
APPENDIX D: SystemVut Controller CCN Tables
Status Display Tables
TABLE DISPLAY NAME VALUES UNITS POINT NAME WRITE STATUS
UINPUT
Supply Air Temperature xxx..x °F SAT
Outdoor Air Temperature xxx.x °F OAT Forcible
Return Air Te mpe rature xxx.x °F RAT Forcible
Space Temperature xxx.x °F SPACE_T Forcible
Space Tempe rature Offset xx.x ΔF SPTO Forcible
Fan Supply Air Temp xxx.x °F FST
Cir.A Sat.Suction Temp xxx.x °F SST_A
Cir.A Sat.Discharge Temp xxx.x °F SDT_A
Cir .A Suction Pressure xxx.x PSI SSP_A
Cir .A Discharge Pressure xxx.x PSI SDP_A
Thermostat G Input On/Off G Forcible
Thermostat Y1 Input On/Off Y1 Forcible
Thermostat Y2 Input On/Off Y2 Forcible
Thermostat W1 Input On/Off W1 Forcible
Thermostat W2 Input On/Off W2 Forcible
Humidistat Input On/Off HUMDSTAT Forcible
IDF Manual Limit Switch Open/Close IDF_LSM
IGC Fan On Request (IFO) On/Off IGC_IFO
Cir.A High Pressure Sw Open/Close CIRA_HPS
Fire Shutdown Switch Alarm/Normal FIREDOWN Forcible
COFS Switch State High/Low COFS Forcible
Filter Status Switch Dirty/Clean FILTSTAT Forcible
Phase Monitor Switch Alarm/Normal PMR_STAT
Fan Status Switch On/Off FAN_STAT
Remote Occupancy Switch On/Off REMOCC Forcible
Remote Shutdown Switch On/Off REMSHUT Forcible
General Status Switch Alarm/Normal GENSTAT Forcible
IAQ Override Switch On/Off IAQ_OVRS Forcible
Enthalpy Switch High/Low ENTH_SW Forcible
Damper Actual Position 0 to 100 % DAMPPOS
Space Relative Humidity 0 to 100 % SPRH Forcible
OA Relative Humidity 0 to 100 % OARH Forcible
RA Relative Humidity 0 to 100 % RARH Forcible
Indoor Air Quality Level xxxx PPM IAQ Forcible
OA Quality Level xxxx PPM OAQ Forcible
Outdoor Air in CFM 0 t o 8000 CFM OACFM Forcible
UOUTPUT
IDF Commanded RPM 0 to 3000 RPM FSPD_RPM
Econo Commanded Position 0 to 100 % DAMPCMD Forcible
CCH Relay 1 State On/Off CCHR1
Power Exhaust 1 Relay On/Off PE1 Forcible
Power Exhaust 2 Relay On/Off PE2 Forcible
Alarm Output Relay State On/Off ALMOUT Forcible
2--- Pos Damper/ERV relay On/Off ERV_2POS
Circuit A Compressor 1 On/Off COMP_A1
Circuit A CMP A1 Loader On/Off COMP_ALD
Outdoor Fan Speed Relay On/Off OFR
Heat Stage 1 Relay On/Off HEAT_1
Heat Stage 2 Relay On/Off HEAT_2
Reheat Dischg Valve CirA On/Off RDV_A
Reheat Liquid Valve CirA On/Off RLV_A
Cooling Liq Valve CirA On/Off CLV_A
