SHANDONG CARTER HEAVY INDUSTRY MACHINERY CO., LTD.
38
2.2 Main performance parameters
Appearance parameters
Overall dimensions
CT12BU/CT12B4U
Unit:mm
A Wheel track 1062
B Overall length of track 1404
C The counterweight ground clearance 324
D Tail turning radius 546
E Chassis width(scalable) 850/1100
F Crawler width 180
G Crawler height 324
H Transportation length 3058
IOverallheight（Driving shed top）
2323
Deflection angle left °/ right ° 50°/40°
Gradeability 18
