Carter CT12 - Fuel System

SHANDONG CARTER HEAVY INDUSTRY MACHINERY CO., LTD.
71
5.4.5 Fuel system
The division of ct12 product series is based on different selected engines, mainly involving YANMAR 3TNV70-SSY /
3TNV74F diesel engine, Kubota D722-E48-CBH diesel engine and YOUPU diesel engine. Finally, a brief introduction of
various models of diesel engines is attached.
Capacity of fuel tank:15L
Parts Quantity
Interval (h)
10 50 100 250 500 1000 2000
Check and Refill Fuel Tank Level 1
★
Drain Fuel Tank
★
Drain Fuel Filter / Water Separator 1+1
★
Check the oil-water separator 1
★
Change the oil-water separator 1
★
Check the fuel
hose
Leakage --
★
Crack / twist / others --
★
★Maintenance interval under normal conditions
Recommended fuel:
Merely use the quality diesel (selection of fuel grade should be dependent on environmental temperature).
Fill up the fuel
1.
Park machine on the flat ground.
2.
Lower the bucket onto ground.
4.
Idle engine at low speed for 5min.
5.
Shut down engine Unplug the ignition key.
Caution: fuel should be disposed carefully. Before filling of fuel, shut down engine. No smoking before
filling fuel or with fuel system working.
6.
Pay attention to the fuel scale. Add the fuel if needed.
Important: keep any dirt, dust, water or other foreign material from getting into fuel system!
7. While filling of fuel tank, make sure the fuel is not sprayed on machine and added properly.
8.
Put the cap back on fuel filler to avoid any lost or damage.
