8.Schedule
8.1 Engine configuration
Attachment Ⅰ:
3TNV70-SSY
Engine Model 3TNV70-SSY
Type 4 cycle, in-line, Water-cooled Diesel engine
Combustion
System
Indirect injecction
Aspiration Natural
No. of Cylinders 3
Bore × Stroke 2.756 x 2.913 in. (70 × 74 mm)
Displacement 52.105 cu in. (0.854 L)
Rated Output
RPM(min-1) 1500 1800 2000 2200 2400 2600
kW 6.69 8.02 8.97 10 11.0 11.8
PS 9.10 10.9 12.2 13.6 14.9 16.1
High Idling RPM(min-1) 1600± 25 1895± 25 2160± 25 2375± 25 2570± 25 2780± 25
Engine Weight
(Dry) with
Flywheel
Housing
106 kg
Direction of
Rotation
Counterclockwise Viewed from Flywheel End
Cooling System Liquid-Cooled with Radiator
Lubricating
System
Forced Lubrication with Trochoid Pump
